| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_024T01_9000002810_18783cztM0_level2.evt | modeM0/AS1A05_024T01_9000002810_18783cztM0_level2_quad_clean.evt |
| Size (bytes) | 446,140,800 | 95,644,800 |
| Size | 425.5 MB | 91.2 MB |
| Events in quadrant A | 3,130,608 | 614,869 |
| Events in quadrant B | 3,210,820 | 630,196 |
| Events in quadrant C | 3,242,265 | 605,725 |
| Events in quadrant D | 3,481,252 | 587,698 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13414 | 2 |
| B | 0 | 13555 | 2 |
| C | 0 | 13556 | 2 |
| D | 0 | 14703 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6573 | 25 | 0.380344% |
| B | 6573 | 25 | 0.380344% |
| C | 6573 | 71 | 1.080176% |
| D | 6573 | 46 | 0.699833% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7608 | 6574 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7608 | 6574 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7608 | 6574 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7608 | 6574 | 18 | 18 | 0.24% | 0.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 9875 | 55.74 | 805 | 790 | 163.0 |
| A | 13 | 254 | 9603 | 54.07 | 805 | 790 | 163.0 |
| A | 9 | 143 | 8078 | 44.71 | 805 | 790 | 163.0 |
| B | 12 | 111 | 18402 | 114.56 | 806 | 785 | 153.8 |
| B | 11 | 111 | 15895 | 98.26 | 806 | 785 | 153.8 |
| B | 4 | 216 | 15045 | 92.73 | 806 | 785 | 153.8 |
| C | 14 | 238 | 124996 | 668.54 | 788 | 794 | 185.8 |
| C | 3 | 233 | 35575 | 187.22 | 788 | 794 | 185.8 |
| C | 5 | 112 | 7498 | 36.09 | 788 | 794 | 185.8 |
| D | 1 | 52 | 444028 | 2301.69 | 790 | 767 | 192.6 |
| D | 12 | 110 | 33631 | 170.65 | 790 | 767 | 192.6 |
| D | 2 | 234 | 25082 | 126.26 | 790 | 767 | 192.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
