| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_194T13_9000002814_18846cztM0_level2.evt | modeM0/AS1A05_194T13_9000002814_18846cztM0_level2_quad_clean.evt |
| Size (bytes) | 506,252,160 | 73,175,040 |
| Size | 482.8 MB | 69.8 MB |
| Events in quadrant A | 3,448,094 | 461,722 |
| Events in quadrant B | 3,694,588 | 463,831 |
| Events in quadrant C | 3,492,536 | 433,988 |
| Events in quadrant D | 4,274,206 | 421,254 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13901 | 2 |
| B | 0 | 14739 | 2 |
| C | 0 | 13942 | 2 |
| D | 0 | 16438 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6235 | 59 | 0.946271% |
| B | 6235 | 118 | 1.892542% |
| C | 6235 | 93 | 1.491580% |
| D | 6234 | 234 | 3.753609% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7590 | 6236 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7590 | 6236 | 25 | 25 | 0.33% | 0.40% |  |
| C | 7590 | 6236 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7589 | 6235 | 163 | 163 | 2.15% | 2.61% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 29 | 11543 | 60.72 | 886 | 871 | 175.8 |
| A | 10 | 1 | 10327 | 53.8 | 886 | 871 | 175.8 |
| A | 13 | 254 | 9754 | 50.54 | 886 | 871 | 175.8 |
| B | 7 | 220 | 139507 | 852.38 | 876 | 860 | 162.7 |
| B | 4 | 216 | 37833 | 227.3 | 876 | 860 | 162.7 |
| B | 0 | 229 | 29578 | 176.55 | 876 | 860 | 162.7 |
| C | 14 | 238 | 130720 | 684.0 | 822 | 832 | 189.9 |
| C | 3 | 233 | 112600 | 588.58 | 822 | 832 | 189.9 |
| C | 0 | 207 | 23089 | 117.21 | 822 | 832 | 189.9 |
| D | 1 | 20 | 582320 | 2885.59 | 829 | 806 | 201.5 |
| D | 1 | 52 | 287950 | 1424.86 | 829 | 806 | 201.5 |
| D | 7 | 238 | 152341 | 751.95 | 829 | 806 | 201.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
