| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_194T13_9000002814_18847cztM0_level2.evt | modeM0/AS1A05_194T13_9000002814_18847cztM0_level2_quad_clean.evt |
| Size (bytes) | 347,518,080 | 70,237,440 |
| Size | 331.4 MB | 67.0 MB |
| Events in quadrant A | 2,372,291 | 466,861 |
| Events in quadrant B | 2,485,706 | 468,913 |
| Events in quadrant C | 2,408,044 | 438,771 |
| Events in quadrant D | 2,943,491 | 427,313 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9716 | 1 |
| B | 0 | 10037 | 1 |
| C | 0 | 9812 | 1 |
| D | 0 | 11530 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 94 | 0 |
| B | 0 | 94 | 0 |
| C | 0 | 94 | 0 |
| D | 0 | 94 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4627 | 9 | 0.194510% |
| B | 4627 | 25 | 0.540307% |
| C | 4627 | 34 | 0.734817% |
| D | 4628 | 119 | 2.571305% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5982 | 4628 | 0 | 0 | 0.00% | 0.00% |  |
| B | 5982 | 4628 | 0 | 0 | 0.00% | 0.00% |  |
| C | 5982 | 4628 | 2 | 2 | 0.03% | 0.04% |  |
| D | 5983 | 4629 | 92 | 92 | 1.54% | 1.99% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 7601 | 56.83 | 613 | 602 | 123.1 |
| A | 11 | 29 | 5967 | 43.56 | 613 | 602 | 123.1 |
| A | 0 | 226 | 5364 | 38.67 | 613 | 602 | 123.1 |
| B | 7 | 220 | 50949 | 441.55 | 605 | 593 | 114.0 |
| B | 4 | 216 | 21461 | 182.98 | 605 | 593 | 114.0 |
| B | 0 | 229 | 15284 | 128.82 | 605 | 593 | 114.0 |
| C | 14 | 238 | 90308 | 676.8 | 574 | 580 | 132.6 |
| C | 3 | 233 | 33413 | 247.65 | 574 | 580 | 132.6 |
| C | 5 | 112 | 23320 | 171.52 | 574 | 580 | 132.6 |
| D | 1 | 20 | 315692 | 2257.33 | 582 | 567 | 139.6 |
| D | 1 | 52 | 261504 | 1869.16 | 582 | 567 | 139.6 |
| D | 7 | 238 | 55588 | 394.13 | 582 | 567 | 139.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
