| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_003T07_9000002818_18884cztM0_level2.evt | modeM0/AS1A06_003T07_9000002818_18884cztM0_level2_quad_clean.evt |
| Size (bytes) | 482,938,560 | 97,945,920 |
| Size | 460.6 MB | 93.4 MB |
| Events in quadrant A | 3,630,306 | 633,200 |
| Events in quadrant B | 3,166,521 | 647,263 |
| Events in quadrant C | 3,117,957 | 625,387 |
| Events in quadrant D | 4,263,857 | 601,136 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15226 | 2 |
| B | 0 | 13863 | 2 |
| C | 0 | 13620 | 2 |
| D | 0 | 17287 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6585 | 105 | 1.594533% |
| B | 6585 | 33 | 0.501139% |
| C | 6585 | 51 | 0.774487% |
| D | 6584 | 174 | 2.642770% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7605 | 6586 | 60 | 60 | 0.79% | 0.91% |  |
| B | 7605 | 6586 | 6 | 6 | 0.08% | 0.09% |  |
| C | 7605 | 6586 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7604 | 6585 | 122 | 122 | 1.60% | 1.85% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 647227 | 4158.09 | 769 | 754 | 155.5 |
| A | 13 | 254 | 11604 | 69.79 | 769 | 754 | 155.5 |
| A | 0 | 13 | 7764 | 45.09 | 769 | 754 | 155.5 |
| B | 7 | 220 | 72806 | 485.0 | 773 | 753 | 148.6 |
| B | 0 | 189 | 28299 | 185.42 | 773 | 753 | 148.6 |
| B | 12 | 111 | 17346 | 111.69 | 773 | 753 | 148.6 |
| C | 14 | 238 | 116596 | 662.52 | 747 | 750 | 174.9 |
| C | 3 | 233 | 63279 | 357.6 | 747 | 750 | 174.9 |
| C | 9 | 54 | 23392 | 129.49 | 747 | 750 | 174.9 |
| D | 1 | 52 | 659023 | 3638.76 | 744 | 723 | 180.9 |
| D | 12 | 1 | 311930 | 1720.2 | 744 | 723 | 180.9 |
| D | 12 | 110 | 208043 | 1145.96 | 744 | 723 | 180.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
