| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_163T01_9000002820_18940cztM0_level2.evt | modeM0/AS1A05_163T01_9000002820_18940cztM0_level2_quad_clean.evt |
| Size (bytes) | 931,328,640 | 96,307,200 |
| Size | 888.2 MB | 91.8 MB |
| Events in quadrant A | 11,687,716 | 472,227 |
| Events in quadrant B | 6,126,439 | 627,100 |
| Events in quadrant C | 4,465,255 | 623,749 |
| Events in quadrant D | 5,360,712 | 610,353 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 40271 | 1 |
| B | 0 | 23648 | 1 |
| C | 0 | 18534 | 1 |
| D | 0 | 21875 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 172 | 0 |
| B | 0 | 172 | 0 |
| C | 0 | 172 | 0 |
| D | 0 | 172 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8367 | 2797 | 33.428947% |
| B | 8368 | 688 | 8.221797% |
| C | 8368 | 100 | 1.195029% |
| D | 8368 | 328 | 3.919694% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8912 | 8368 | 2185 | 2185 | 24.52% | 26.11% |  |
| B | 8913 | 8369 | 407 | 407 | 4.57% | 4.86% |  |
| C | 8913 | 8369 | 14 | 14 | 0.16% | 0.17% |  |
| D | 8913 | 8369 | 240 | 240 | 2.69% | 2.87% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 8339855 | 48196.21 | 850 | 832 | 173.0 |
| A | 6 | 16 | 58435 | 332.92 | 850 | 832 | 173.0 |
| A | 13 | 254 | 11617 | 62.33 | 850 | 832 | 173.0 |
| B | 3 | 112 | 2110786 | 11489.61 | 955 | 930 | 183.6 |
| B | 0 | 189 | 71185 | 382.59 | 955 | 930 | 183.6 |
| B | 7 | 220 | 63909 | 342.96 | 955 | 930 | 183.6 |
| C | 3 | 233 | 601493 | 2699.36 | 949 | 954 | 222.5 |
| C | 14 | 238 | 146922 | 656.11 | 949 | 954 | 222.5 |
| C | 8 | 128 | 10652 | 43.59 | 949 | 954 | 222.5 |
| D | 7 | 238 | 719421 | 3073.11 | 949 | 920 | 233.8 |
| D | 12 | 218 | 475039 | 2027.86 | 949 | 920 | 233.8 |
| D | 1 | 52 | 315582 | 1345.85 | 949 | 920 | 233.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
