| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_090T01_9000002822_18946cztM0_level2.evt | modeM0/AS1T03_090T01_9000002822_18946cztM0_level2_quad_clean.evt |
| Size (bytes) | 652,432,320 | 83,871,360 |
| Size | 622.2 MB | 80.0 MB |
| Events in quadrant A | 3,771,282 | 552,600 |
| Events in quadrant B | 3,600,393 | 569,881 |
| Events in quadrant C | 3,240,821 | 554,568 |
| Events in quadrant D | 8,734,690 | 437,177 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14877 | 1 |
| B | 0 | 14463 | 1 |
| C | 0 | 13249 | 1 |
| D | 0 | 30200 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6086 | 94 | 1.544528% |
| B | 6087 | 87 | 1.429276% |
| C | 6087 | 70 | 1.149992% |
| D | 6086 | 2281 | 37.479461% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7446 | 6087 | 58 | 58 | 0.78% | 0.95% |  |
| B | 7447 | 6088 | 27 | 27 | 0.36% | 0.44% |  |
| C | 7447 | 6088 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7446 | 6087 | 1252 | 1252 | 16.81% | 20.57% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 661622 | 4167.29 | 805 | 792 | 158.6 |
| A | 11 | 29 | 9660 | 55.92 | 805 | 792 | 158.6 |
| A | 13 | 254 | 8160 | 46.46 | 805 | 792 | 158.6 |
| B | 3 | 112 | 187923 | 1272.21 | 810 | 793 | 147.1 |
| B | 7 | 220 | 142815 | 965.54 | 810 | 793 | 147.1 |
| B | 0 | 189 | 80417 | 541.32 | 810 | 793 | 147.1 |
| C | 14 | 238 | 129659 | 711.82 | 794 | 800 | 181.0 |
| C | 3 | 233 | 15202 | 79.55 | 794 | 800 | 181.0 |
| C | 13 | 61 | 5633 | 26.69 | 794 | 800 | 181.0 |
| D | 7 | 238 | 5958340 | 36577.98 | 684 | 664 | 162.9 |
| D | 1 | 52 | 72766 | 442.68 | 684 | 664 | 162.9 |
| D | 12 | 233 | 67110 | 407.95 | 684 | 664 | 162.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
