| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_205T01_9000002824_18961cztM0_level2.evt | modeM0/AS1A05_205T01_9000002824_18961cztM0_level2_quad_clean.evt |
| Size (bytes) | 500,935,680 | 87,330,240 |
| Size | 477.7 MB | 83.3 MB |
| Events in quadrant A | 2,868,770 | 567,704 |
| Events in quadrant B | 5,222,313 | 570,263 |
| Events in quadrant C | 2,972,359 | 567,454 |
| Events in quadrant D | 3,724,677 | 544,575 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11742 | 1 |
| B | 0 | 19251 | 1 |
| C | 0 | 12040 | 1 |
| D | 0 | 14558 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5637 | 14 | 0.248359% |
| B | 5638 | 738 | 13.089748% |
| C | 5638 | 40 | 0.709471% |
| D | 5638 | 125 | 2.217098% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7027 | 5638 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7028 | 5639 | 478 | 478 | 6.80% | 8.48% |  |
| C | 7028 | 5639 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7028 | 5639 | 89 | 89 | 1.27% | 1.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 21038 | 138.2 | 738 | 723 | 147.0 |
| A | 8 | 144 | 7215 | 44.16 | 738 | 723 | 147.0 |
| A | 0 | 226 | 6443 | 38.91 | 738 | 723 | 147.0 |
| B | 3 | 112 | 2279023 | 17315.6 | 705 | 689 | 131.6 |
| B | 7 | 220 | 88760 | 669.35 | 705 | 689 | 131.6 |
| B | 0 | 189 | 57718 | 433.43 | 705 | 689 | 131.6 |
| C | 14 | 238 | 113837 | 661.29 | 731 | 738 | 171.0 |
| C | 6 | 96 | 8854 | 47.45 | 731 | 738 | 171.0 |
| C | 13 | 61 | 5026 | 25.07 | 731 | 738 | 171.0 |
| D | 7 | 238 | 471585 | 2696.6 | 727 | 707 | 174.6 |
| D | 12 | 218 | 275771 | 1575.22 | 727 | 707 | 174.6 |
| D | 1 | 52 | 147167 | 838.74 | 727 | 707 | 174.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
