| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_003T05_9000002830_19003cztM0_level2.evt | modeM0/AS1A06_003T05_9000002830_19003cztM0_level2_quad_clean.evt |
| Size (bytes) | 568,575,360 | 88,295,040 |
| Size | 542.2 MB | 84.2 MB |
| Events in quadrant A | 5,371,003 | 541,743 |
| Events in quadrant B | 3,281,843 | 608,320 |
| Events in quadrant C | 3,195,180 | 570,561 |
| Events in quadrant D | 4,949,456 | 518,073 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20059 | 2 |
| B | 0 | 13588 | 2 |
| C | 0 | 13202 | 2 |
| D | 0 | 19055 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6222 | 804 | 12.921890% |
| B | 6222 | 63 | 1.012536% |
| C | 6222 | 58 | 0.932176% |
| D | 6222 | 366 | 5.882353% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7492 | 6223 | 548 | 548 | 7.31% | 8.81% |  |
| B | 7492 | 6223 | 11 | 11 | 0.15% | 0.18% |  |
| C | 7492 | 6223 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7492 | 6223 | 303 | 303 | 4.04% | 4.87% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 2508936 | 16823.29 | 742 | 728 | 149.1 |
| A | 0 | 226 | 6641 | 39.66 | 742 | 728 | 149.1 |
| A | 8 | 144 | 6032 | 35.58 | 742 | 728 | 149.1 |
| B | 3 | 112 | 143683 | 956.78 | 792 | 776 | 149.4 |
| B | 12 | 111 | 17522 | 112.12 | 792 | 776 | 149.4 |
| B | 11 | 111 | 14807 | 93.94 | 792 | 776 | 149.4 |
| C | 14 | 238 | 121156 | 685.4 | 757 | 763 | 175.7 |
| C | 3 | 233 | 119657 | 676.86 | 757 | 763 | 175.7 |
| C | 13 | 61 | 5242 | 25.5 | 757 | 763 | 175.7 |
| D | 7 | 238 | 1805080 | 10115.78 | 735 | 717 | 178.4 |
| D | 1 | 52 | 269412 | 1506.38 | 735 | 717 | 178.4 |
| D | 9 | 68 | 46144 | 254.68 | 735 | 717 | 178.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
