| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_003T05_9000002830_19006cztM0_level2.evt | modeM0/AS1A06_003T05_9000002830_19006cztM0_level2_quad_clean.evt |
| Size (bytes) | 648,069,120 | 62,262,720 |
| Size | 618.0 MB | 59.4 MB |
| Events in quadrant A | 6,035,233 | 334,346 |
| Events in quadrant B | 3,491,408 | 389,741 |
| Events in quadrant C | 3,332,281 | 365,902 |
| Events in quadrant D | 6,333,090 | 346,334 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22060 | 1 |
| B | 0 | 14034 | 1 |
| C | 0 | 13525 | 1 |
| D | 0 | 23107 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6429 | 940 | 14.621247% |
| B | 6429 | 91 | 1.415461% |
| C | 6429 | 51 | 0.793280% |
| D | 6430 | 967 | 15.038880% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7749 | 6430 | 602 | 602 | 7.77% | 9.36% |  |
| B | 7749 | 6430 | 22 | 22 | 0.28% | 0.34% |  |
| C | 7749 | 6430 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7749 | 6430 | 865 | 865 | 11.16% | 13.45% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 2940386 | 18538.72 | 795 | 781 | 158.6 |
| A | 0 | 13 | 36445 | 224.92 | 795 | 781 | 158.6 |
| A | 0 | 226 | 6865 | 38.37 | 795 | 781 | 158.6 |
| B | 3 | 112 | 86581 | 537.9 | 845 | 827 | 159.4 |
| B | 15 | 201 | 57478 | 355.35 | 845 | 827 | 159.4 |
| B | 12 | 111 | 18817 | 112.84 | 845 | 827 | 159.4 |
| C | 14 | 238 | 127715 | 685.38 | 799 | 806 | 185.2 |
| C | 3 | 233 | 84934 | 454.34 | 799 | 806 | 185.2 |
| C | 13 | 61 | 5596 | 25.87 | 799 | 806 | 185.2 |
| D | 2 | 233 | 2086876 | 11737.19 | 728 | 707 | 177.7 |
| D | 7 | 238 | 870193 | 4891.89 | 728 | 707 | 177.7 |
| D | 1 | 52 | 605841 | 3404.6 | 728 | 707 | 177.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
