| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_003T05_9000002830_19019cztM0_level2.evt | modeM0/AS1A06_003T05_9000002830_19019cztM0_level2_quad_clean.evt |
| Size (bytes) | 544,613,760 | 81,673,920 |
| Size | 519.4 MB | 77.9 MB |
| Events in quadrant A | 4,127,537 | 516,515 |
| Events in quadrant B | 3,367,725 | 547,171 |
| Events in quadrant C | 4,353,060 | 500,096 |
| Events in quadrant D | 4,223,884 | 474,923 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16013 | 3 |
| B | 0 | 13666 | 2 |
| C | 0 | 16992 | 2 |
| D | 0 | 16639 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6224 | 384 | 6.169666% |
| B | 6224 | 54 | 0.867609% |
| C | 6224 | 231 | 3.711440% |
| D | 6224 | 225 | 3.615039% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7589 | 6225 | 237 | 237 | 3.12% | 3.81% |  |
| B | 7589 | 6225 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7589 | 6225 | 97 | 97 | 1.28% | 1.56% |  |
| D | 7589 | 6225 | 157 | 157 | 2.07% | 2.52% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 1001454 | 6307.34 | 801 | 788 | 158.7 |
| A | 9 | 143 | 28421 | 174.17 | 801 | 788 | 158.7 |
| A | 15 | 191 | 7243 | 40.69 | 801 | 788 | 158.7 |
| B | 0 | 189 | 45658 | 288.51 | 828 | 810 | 155.4 |
| B | 3 | 112 | 37820 | 238.09 | 828 | 810 | 155.4 |
| B | 7 | 220 | 21928 | 135.86 | 828 | 810 | 155.4 |
| C | 3 | 233 | 1197315 | 6619.14 | 778 | 788 | 180.8 |
| C | 14 | 238 | 121877 | 669.86 | 778 | 788 | 180.8 |
| C | 13 | 61 | 5314 | 25.04 | 778 | 788 | 180.8 |
| D | 1 | 52 | 699716 | 3743.03 | 774 | 754 | 186.7 |
| D | 7 | 238 | 584708 | 3127.15 | 774 | 754 | 186.7 |
| D | 2 | 234 | 25402 | 131.99 | 774 | 754 | 186.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
