| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_003T05_9000002830_19020cztM0_level2.evt | modeM0/AS1A06_003T05_9000002830_19020cztM0_level2_quad_clean.evt |
| Size (bytes) | 488,399,040 | 71,645,760 |
| Size | 465.8 MB | 68.3 MB |
| Events in quadrant A | 3,853,011 | 435,003 |
| Events in quadrant B | 3,349,512 | 459,949 |
| Events in quadrant C | 3,279,953 | 427,599 |
| Events in quadrant D | 3,879,577 | 405,461 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 21 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15199 | 2 |
| B | 0 | 13551 | 2 |
| C | 0 | 13435 | 2 |
| D | 0 | 15640 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6325 | 248 | 3.920949% |
| B | 6325 | 47 | 0.743083% |
| C | 6325 | 46 | 0.727273% |
| D | 6324 | 144 | 2.277040% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7700 | 6326 | 136 | 136 | 1.77% | 2.15% |  |
| B | 7700 | 6326 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7700 | 6326 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7699 | 6325 | 112 | 112 | 1.45% | 1.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 692514 | 4218.26 | 819 | 803 | 164.0 |
| A | 15 | 191 | 7838 | 42.9 | 819 | 803 | 164.0 |
| A | 0 | 226 | 7128 | 38.57 | 819 | 803 | 164.0 |
| B | 7 | 220 | 41268 | 255.83 | 839 | 820 | 158.1 |
| B | 3 | 112 | 18582 | 112.34 | 839 | 820 | 158.1 |
| B | 12 | 111 | 18293 | 110.52 | 839 | 820 | 158.1 |
| C | 14 | 238 | 126557 | 686.79 | 790 | 798 | 183.1 |
| C | 3 | 233 | 68413 | 369.26 | 790 | 798 | 183.1 |
| C | 13 | 61 | 5657 | 26.54 | 790 | 798 | 183.1 |
| D | 1 | 52 | 544155 | 2845.91 | 787 | 765 | 190.9 |
| D | 7 | 238 | 328460 | 1716.25 | 787 | 765 | 190.9 |
| D | 2 | 234 | 23739 | 120.32 | 787 | 765 | 190.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
