| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_022T03_9000002832_19027cztM0_level2.evt | modeM0/AS1A05_022T03_9000002832_19027cztM0_level2_quad_clean.evt |
| Size (bytes) | 884,805,120 | 82,785,600 |
| Size | 843.8 MB | 79.0 MB |
| Events in quadrant A | 3,819,965 | 558,780 |
| Events in quadrant B | 4,282,000 | 560,964 |
| Events in quadrant C | 3,961,965 | 539,418 |
| Events in quadrant D | 14,188,061 | 287,252 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16601 | 2 |
| B | 0 | 17777 | 2 |
| C | 0 | 16847 | 2 |
| D | 0 | 47493 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 164 | 0 |
| B | 0 | 164 | 0 |
| C | 0 | 164 | 0 |
| D | 0 | 164 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8051 | 145 | 1.801019% |
| B | 8051 | 241 | 2.993417% |
| C | 8051 | 194 | 2.409639% |
| D | 8051 | 4374 | 54.328655% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9146 | 8053 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9146 | 8053 | 36 | 36 | 0.39% | 0.45% |  |
| C | 9146 | 8053 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9146 | 8052 | 3963 | 3963 | 43.33% | 49.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 9678 | 43.29 | 989 | 966 | 201.2 |
| A | 0 | 226 | 8546 | 37.67 | 989 | 966 | 201.2 |
| A | 3 | 137 | 8026 | 35.08 | 989 | 966 | 201.2 |
| B | 3 | 112 | 305087 | 1575.7 | 984 | 956 | 193.0 |
| B | 7 | 220 | 54284 | 276.29 | 984 | 956 | 193.0 |
| B | 0 | 190 | 30047 | 150.72 | 984 | 956 | 193.0 |
| C | 14 | 238 | 146955 | 652.62 | 948 | 952 | 223.7 |
| C | 3 | 233 | 117192 | 519.58 | 948 | 952 | 223.7 |
| C | 13 | 61 | 6628 | 25.37 | 948 | 952 | 223.7 |
| D | 1 | 52 | 9814110 | 74253.03 | 539 | 523 | 132.2 |
| D | 7 | 238 | 2299829 | 17397.35 | 539 | 523 | 132.2 |
| D | 2 | 234 | 22185 | 163.9 | 539 | 523 | 132.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
