| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_046T01_9000002834_19038cztM0_level2.evt | modeM0/AS1A05_046T01_9000002834_19038cztM0_level2_quad_clean.evt |
| Size (bytes) | 738,345,600 | 82,393,920 |
| Size | 704.1 MB | 78.6 MB |
| Events in quadrant A | 3,386,545 | 526,752 |
| Events in quadrant B | 3,620,857 | 540,383 |
| Events in quadrant C | 4,355,142 | 518,823 |
| Events in quadrant D | 10,519,082 | 415,196 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14679 | 1 |
| B | 0 | 15145 | 1 |
| C | 0 | 17211 | 1 |
| D | 0 | 36105 | 5 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7083 | 242 | 3.416631% |
| B | 7084 | 261 | 3.684359% |
| C | 7084 | 325 | 4.587804% |
| D | 7083 | 2868 | 40.491317% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7228 | 7085 | 3 | 3 | 0.04% | 0.04% |  |
| B | 7229 | 7086 | 22 | 22 | 0.30% | 0.31% |  |
| C | 7229 | 7086 | 45 | 45 | 0.62% | 0.64% |  |
| D | 7228 | 7083 | 2261 | 2261 | 31.28% | 31.92% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 8896 | 45.34 | 876 | 854 | 177.4 |
| A | 13 | 210 | 8694 | 44.2 | 876 | 854 | 177.4 |
| A | 0 | 226 | 7690 | 38.54 | 876 | 854 | 177.4 |
| B | 3 | 112 | 56767 | 330.12 | 870 | 846 | 169.4 |
| B | 4 | 216 | 51990 | 301.92 | 870 | 846 | 169.4 |
| B | 7 | 220 | 49615 | 287.9 | 870 | 846 | 169.4 |
| C | 3 | 233 | 878441 | 4459.6 | 840 | 844 | 196.8 |
| C | 14 | 238 | 127971 | 646.01 | 840 | 844 | 196.8 |
| C | 9 | 15 | 72997 | 366.65 | 840 | 844 | 196.8 |
| D | 7 | 238 | 7802142 | 45461.23 | 702 | 681 | 171.6 |
| D | 2 | 234 | 29986 | 170.77 | 702 | 681 | 171.6 |
| D | 7 | 38 | 15676 | 87.38 | 702 | 681 | 171.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
