| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_046T01_9000002834_19050cztM0_level2.evt | modeM0/AS1A05_046T01_9000002834_19050cztM0_level2_quad_clean.evt |
| Size (bytes) | 439,706,880 | 87,007,680 |
| Size | 419.3 MB | 83.0 MB |
| Events in quadrant A | 3,046,446 | 553,497 |
| Events in quadrant B | 3,265,064 | 566,592 |
| Events in quadrant C | 3,234,085 | 546,783 |
| Events in quadrant D | 3,345,681 | 531,169 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12971 | 1 |
| B | 0 | 13628 | 1 |
| C | 0 | 13249 | 1 |
| D | 0 | 14083 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6253 | 53 | 0.847593% |
| B | 6253 | 100 | 1.599232% |
| C | 6253 | 83 | 1.327363% |
| D | 6253 | 47 | 0.751639% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7408 | 6254 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7408 | 6254 | 9 | 9 | 0.12% | 0.14% |  |
| C | 7408 | 6254 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7408 | 6254 | 7 | 7 | 0.09% | 0.11% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 8364 | 47.43 | 791 | 774 | 160.0 |
| A | 0 | 226 | 6926 | 38.44 | 791 | 774 | 160.0 |
| A | 3 | 137 | 5781 | 31.29 | 791 | 774 | 160.0 |
| B | 7 | 220 | 100136 | 652.77 | 785 | 766 | 152.2 |
| B | 4 | 216 | 43704 | 282.06 | 785 | 766 | 152.2 |
| B | 0 | 189 | 19623 | 123.87 | 785 | 766 | 152.2 |
| C | 14 | 238 | 118148 | 656.75 | 761 | 767 | 178.7 |
| C | 9 | 15 | 86939 | 482.14 | 761 | 767 | 178.7 |
| C | 3 | 233 | 53972 | 297.68 | 761 | 767 | 178.7 |
| D | 7 | 238 | 377694 | 2013.57 | 772 | 753 | 187.2 |
| D | 2 | 234 | 25853 | 134.08 | 772 | 753 | 187.2 |
| D | 7 | 38 | 15111 | 76.7 | 772 | 753 | 187.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
