| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_046T01_9000002834_19079cztM0_level2.evt | modeM0/AS1A05_046T01_9000002834_19079cztM0_level2_quad_clean.evt |
| Size (bytes) | 521,818,560 | 99,653,760 |
| Size | 497.6 MB | 95.0 MB |
| Events in quadrant A | 3,345,282 | 637,454 |
| Events in quadrant B | 3,623,924 | 655,839 |
| Events in quadrant C | 3,565,917 | 633,967 |
| Events in quadrant D | 4,802,876 | 613,084 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14282 | 2 |
| B | 0 | 15163 | 2 |
| C | 0 | 14777 | 3 |
| D | 0 | 18893 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6853 | 37 | 0.539910% |
| B | 6853 | 95 | 1.386254% |
| C | 6852 | 89 | 1.298891% |
| D | 6852 | 648 | 9.457093% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7978 | 6854 | 3 | 3 | 0.04% | 0.04% |  |
| B | 7978 | 6854 | 18 | 18 | 0.23% | 0.26% |  |
| C | 7977 | 6853 | 11 | 11 | 0.14% | 0.16% |  |
| D | 7977 | 6853 | 472 | 472 | 5.92% | 6.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 14965 | 80.89 | 862 | 844 | 174.6 |
| A | 15 | 174 | 10714 | 56.54 | 862 | 844 | 174.6 |
| A | 13 | 254 | 8287 | 42.64 | 862 | 844 | 174.6 |
| B | 7 | 220 | 158672 | 953.75 | 863 | 842 | 165.5 |
| B | 3 | 112 | 38030 | 224.72 | 863 | 842 | 165.5 |
| B | 12 | 111 | 19289 | 111.47 | 863 | 842 | 165.5 |
| C | 14 | 238 | 130841 | 661.85 | 837 | 847 | 196.4 |
| C | 0 | 207 | 80178 | 403.9 | 837 | 847 | 196.4 |
| C | 3 | 233 | 77312 | 389.31 | 837 | 847 | 196.4 |
| D | 1 | 52 | 1466387 | 7419.66 | 812 | 791 | 197.5 |
| D | 7 | 238 | 150572 | 758.27 | 812 | 791 | 197.5 |
| D | 11 | 176 | 123669 | 622.08 | 812 | 791 | 197.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
