| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_046T01_9000002834_19093cztM0_level2.evt | modeM0/AS1A05_046T01_9000002834_19093cztM0_level2_quad_clean.evt |
| Size (bytes) | 271,111,680 | 64,241,280 |
| Size | 258.6 MB | 61.3 MB |
| Events in quadrant A | 1,894,087 | 416,004 |
| Events in quadrant B | 2,063,905 | 431,641 |
| Events in quadrant C | 1,997,225 | 415,996 |
| Events in quadrant D | 1,982,316 | 399,717 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 84 | 0 |
| B | 0 | 84 | 0 |
| C | 0 | 84 | 0 |
| D | 0 | 84 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8165 | 1 |
| B | 0 | 8603 | 1 |
| C | 0 | 8340 | 1 |
| D | 0 | 8538 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3989 | 9 | 0.225620% |
| B | 3989 | 46 | 1.153171% |
| C | 3989 | 38 | 0.952620% |
| D | 3990 | 20 | 0.501253% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5314 | 3990 | 0 | 0 | 0.00% | 0.00% |  |
| B | 5314 | 3990 | 2 | 2 | 0.04% | 0.05% |  |
| C | 5314 | 3990 | 2 | 2 | 0.04% | 0.05% |  |
| D | 5315 | 3991 | 12 | 12 | 0.23% | 0.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 4135 | 36.29 | 492 | 483 | 100.6 |
| A | 13 | 254 | 4100 | 35.94 | 492 | 483 | 100.6 |
| A | 3 | 137 | 3604 | 31.01 | 492 | 483 | 100.6 |
| B | 0 | 189 | 69002 | 728.66 | 494 | 483 | 94.0 |
| B | 6 | 36 | 22204 | 230.99 | 494 | 483 | 94.0 |
| B | 3 | 112 | 19352 | 200.66 | 494 | 483 | 94.0 |
| C | 14 | 238 | 75329 | 656.76 | 483 | 488 | 114.0 |
| C | 0 | 207 | 18300 | 156.31 | 483 | 488 | 114.0 |
| C | 3 | 233 | 11979 | 100.84 | 483 | 488 | 114.0 |
| D | 7 | 238 | 98964 | 834.65 | 483 | 472 | 118.0 |
| D | 7 | 96 | 35227 | 294.52 | 483 | 472 | 118.0 |
| D | 1 | 52 | 19580 | 161.93 | 483 | 472 | 118.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
