| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_098T01_9000002836_19104cztM0_level2.evt | modeM0/AS1T03_098T01_9000002836_19104cztM0_level2_quad_clean.evt |
| Size (bytes) | 482,734,080 | 77,673,600 |
| Size | 460.4 MB | 74.1 MB |
| Events in quadrant A | 3,170,706 | 482,714 |
| Events in quadrant B | 3,364,043 | 489,486 |
| Events in quadrant C | 3,318,054 | 478,511 |
| Events in quadrant D | 4,343,833 | 466,405 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13549 | 1 |
| B | 0 | 14191 | 1 |
| C | 0 | 14011 | 1 |
| D | 0 | 17360 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6233 | 54 | 0.866356% |
| B | 6234 | 69 | 1.106833% |
| C | 6234 | 100 | 1.604107% |
| D | 6233 | 314 | 5.037703% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7413 | 6234 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7414 | 6235 | 6 | 6 | 0.08% | 0.10% |  |
| C | 7414 | 6235 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7413 | 6234 | 196 | 196 | 2.64% | 3.14% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 19915 | 116.99 | 815 | 798 | 163.4 |
| A | 0 | 226 | 7069 | 38.37 | 815 | 798 | 163.4 |
| A | 13 | 254 | 6599 | 35.5 | 815 | 798 | 163.4 |
| B | 3 | 112 | 53684 | 347.27 | 817 | 797 | 152.3 |
| B | 4 | 216 | 24844 | 157.9 | 817 | 797 | 152.3 |
| B | 7 | 220 | 23031 | 145.99 | 817 | 797 | 152.3 |
| C | 14 | 238 | 125108 | 673.18 | 798 | 807 | 184.6 |
| C | 3 | 233 | 73116 | 391.6 | 798 | 807 | 184.6 |
| C | 0 | 207 | 11293 | 56.79 | 798 | 807 | 184.6 |
| D | 11 | 176 | 628177 | 3267.34 | 793 | 771 | 192.0 |
| D | 7 | 38 | 403378 | 2096.65 | 793 | 771 | 192.0 |
| D | 12 | 218 | 191073 | 991.03 | 793 | 771 | 192.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
