| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_046T01_9000002838_19152cztM0_level2.evt | modeM0/AS1A05_046T01_9000002838_19152cztM0_level2_quad_clean.evt |
| Size (bytes) | 505,152,000 | 102,683,520 |
| Size | 481.8 MB | 97.9 MB |
| Events in quadrant A | 3,525,148 | 648,269 |
| Events in quadrant B | 3,690,777 | 673,544 |
| Events in quadrant C | 3,897,688 | 649,487 |
| Events in quadrant D | 3,689,457 | 630,894 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15259 | 2 |
| B | 0 | 15744 | 2 |
| C | 0 | 16115 | 2 |
| D | 0 | 16008 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7283 | 68 | 0.933681% |
| B | 7284 | 152 | 2.086766% |
| C | 7283 | 132 | 1.812440% |
| D | 7283 | 140 | 1.922285% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9383 | 7285 | 6 | 6 | 0.06% | 0.08% |  |
| B | 9384 | 7286 | 13 | 13 | 0.14% | 0.18% |  |
| C | 9383 | 7284 | 1 | 1 | 0.01% | 0.01% |  |
| D | 9383 | 7285 | 51 | 51 | 0.54% | 0.70% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 57735 | 313.41 | 898 | 880 | 181.4 |
| A | 11 | 29 | 7929 | 38.86 | 898 | 880 | 181.4 |
| A | 0 | 226 | 7780 | 38.03 | 898 | 880 | 181.4 |
| B | 7 | 220 | 93494 | 532.8 | 905 | 882 | 173.8 |
| B | 0 | 190 | 26192 | 145.61 | 905 | 882 | 173.8 |
| B | 3 | 112 | 21199 | 116.88 | 905 | 882 | 173.8 |
| C | 3 | 233 | 337422 | 1620.84 | 879 | 888 | 207.6 |
| C | 14 | 238 | 135202 | 646.89 | 879 | 888 | 207.6 |
| C | 13 | 61 | 6211 | 25.64 | 879 | 888 | 207.6 |
| D | 1 | 52 | 209332 | 964.98 | 884 | 861 | 216.0 |
| D | 11 | 176 | 139076 | 639.78 | 884 | 861 | 216.0 |
| D | 2 | 234 | 27447 | 123.06 | 884 | 861 | 216.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
