| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_046T01_9000002838_19207cztM0_level2.evt | modeM0/AS1A05_046T01_9000002838_19207cztM0_level2_quad_clean.evt |
| Size (bytes) | 479,211,840 | 97,283,520 |
| Size | 457.0 MB | 92.8 MB |
| Events in quadrant A | 3,297,651 | 631,594 |
| Events in quadrant B | 3,444,573 | 652,028 |
| Events in quadrant C | 3,963,232 | 621,325 |
| Events in quadrant D | 3,384,652 | 606,356 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13708 | 2 |
| B | 0 | 14153 | 2 |
| C | 0 | 16135 | 2 |
| D | 0 | 14139 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6227 | 64 | 1.027782% |
| B | 6227 | 76 | 1.220491% |
| C | 6227 | 162 | 2.601574% |
| D | 6227 | 58 | 0.931428% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7562 | 6228 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7562 | 6228 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7562 | 6228 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7562 | 6228 | 20 | 20 | 0.26% | 0.32% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9270 | 49.63 | 852 | 837 | 169.9 |
| A | 0 | 226 | 7468 | 39.03 | 852 | 837 | 169.9 |
| A | 3 | 137 | 6449 | 33.03 | 852 | 837 | 169.9 |
| B | 0 | 190 | 36209 | 219.73 | 861 | 843 | 160.9 |
| B | 12 | 111 | 18194 | 107.8 | 861 | 843 | 160.9 |
| B | 11 | 111 | 16021 | 94.3 | 861 | 843 | 160.9 |
| C | 3 | 233 | 620809 | 3272.68 | 823 | 833 | 189.4 |
| C | 14 | 238 | 131343 | 688.93 | 823 | 833 | 189.4 |
| C | 13 | 61 | 5844 | 26.45 | 823 | 833 | 189.4 |
| D | 10 | 66 | 122726 | 610.93 | 828 | 807 | 199.6 |
| D | 7 | 96 | 69489 | 344.16 | 828 | 807 | 199.6 |
| D | 11 | 176 | 30297 | 147.77 | 828 | 807 | 199.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
