| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_046T01_9000002838_19210cztM0_level2.evt | modeM0/AS1A05_046T01_9000002838_19210cztM0_level2_quad_clean.evt |
| Size (bytes) | 544,337,280 | 96,526,080 |
| Size | 519.1 MB | 92.1 MB |
| Events in quadrant A | 3,171,928 | 617,673 |
| Events in quadrant B | 3,268,513 | 637,440 |
| Events in quadrant C | 4,193,384 | 613,015 |
| Events in quadrant D | 5,400,381 | 590,952 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13764 | 2 |
| B | 0 | 13913 | 2 |
| C | 0 | 17315 | 4 |
| D | 0 | 20696 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6655 | 15 | 0.225394% |
| B | 6655 | 41 | 0.616078% |
| C | 6654 | 104 | 1.562970% |
| D | 6654 | 293 | 4.403366% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7560 | 6656 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7560 | 6656 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7559 | 6655 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7559 | 6655 | 155 | 155 | 2.05% | 2.33% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 29 | 15033 | 85.81 | 818 | 800 | 165.9 |
| A | 13 | 254 | 8093 | 43.97 | 818 | 800 | 165.9 |
| A | 0 | 226 | 7100 | 37.98 | 818 | 800 | 165.9 |
| B | 12 | 111 | 19043 | 115.26 | 824 | 803 | 158.3 |
| B | 11 | 111 | 16809 | 101.14 | 824 | 803 | 158.3 |
| B | 14 | 111 | 14607 | 87.23 | 824 | 803 | 158.3 |
| C | 3 | 233 | 957684 | 5083.0 | 798 | 803 | 188.3 |
| C | 14 | 238 | 122691 | 647.48 | 798 | 803 | 188.3 |
| C | 13 | 61 | 5421 | 24.53 | 798 | 803 | 188.3 |
| D | 10 | 66 | 2331138 | 12033.46 | 794 | 773 | 193.7 |
| D | 11 | 176 | 28543 | 143.4 | 794 | 773 | 193.7 |
| D | 10 | 199 | 27466 | 137.84 | 794 | 773 | 193.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
