| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_007T06_9000002844_19225cztM0_level2.evt | modeM0/AS1A05_007T06_9000002844_19225cztM0_level2_quad_clean.evt |
| Size (bytes) | 465,661,440 | 103,412,160 |
| Size | 444.1 MB | 98.6 MB |
| Events in quadrant A | 3,215,636 | 656,881 |
| Events in quadrant B | 3,268,881 | 678,168 |
| Events in quadrant C | 3,783,995 | 664,669 |
| Events in quadrant D | 3,361,629 | 647,843 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14407 | 2 |
| B | 0 | 14395 | 2 |
| C | 0 | 15701 | 2 |
| D | 0 | 15180 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6957 | 36 | 0.517464% |
| B | 6957 | 42 | 0.603708% |
| C | 6957 | 104 | 1.494897% |
| D | 6957 | 70 | 1.006181% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7647 | 6958 | 7 | 7 | 0.09% | 0.10% |  |
| B | 7647 | 6958 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7647 | 6958 | 1 | 1 | 0.01% | 0.01% |  |
| D | 7647 | 6958 | 24 | 24 | 0.31% | 0.34% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 61959 | 370.91 | 817 | 800 | 164.9 |
| A | 13 | 254 | 9814 | 54.67 | 817 | 800 | 164.9 |
| A | 0 | 226 | 6985 | 37.51 | 817 | 800 | 164.9 |
| B | 0 | 214 | 21400 | 131.5 | 827 | 804 | 156.6 |
| B | 12 | 111 | 19294 | 118.05 | 827 | 804 | 156.6 |
| B | 11 | 111 | 16523 | 100.36 | 827 | 804 | 156.6 |
| C | 3 | 233 | 512997 | 2738.57 | 802 | 807 | 187.0 |
| C | 14 | 238 | 126382 | 671.42 | 802 | 807 | 187.0 |
| C | 5 | 4 | 10296 | 50.74 | 802 | 807 | 187.0 |
| D | 11 | 176 | 186932 | 950.78 | 803 | 779 | 195.8 |
| D | 9 | 68 | 93854 | 475.38 | 803 | 779 | 195.8 |
| D | 2 | 234 | 26900 | 133.41 | 803 | 779 | 195.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
