| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_063T03_9000002840_19211cztM0_level2.evt | modeM0/AS1A05_063T03_9000002840_19211cztM0_level2_quad_clean.evt |
| Size (bytes) | 219,156,480 | 47,266,560 |
| Size | 209.0 MB | 45.1 MB |
| Events in quadrant A | 1,519,593 | 304,409 |
| Events in quadrant B | 1,561,456 | 312,712 |
| Events in quadrant C | 1,863,872 | 300,432 |
| Events in quadrant D | 1,484,579 | 297,748 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 62 | 0 |
| B | 0 | 62 | 0 |
| C | 0 | 62 | 0 |
| D | 0 | 62 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6445 | 2 |
| B | 0 | 6524 | 1 |
| C | 0 | 7671 | 1 |
| D | 0 | 6425 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3029 | 47 | 1.551667% |
| B | 3029 | 80 | 2.641136% |
| C | 3029 | 131 | 4.324860% |
| D | 3029 | 27 | 0.891383% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3439 | 3030 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3439 | 3030 | 0 | 0 | 0.00% | 0.00% |  |
| C | 3439 | 3030 | 0 | 0 | 0.00% | 0.00% |  |
| D | 3439 | 3030 | 1 | 1 | 0.03% | 0.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 247 | 3968 | 43.7 | 393 | 384 | 82.0 |
| A | 13 | 254 | 3538 | 38.46 | 393 | 384 | 82.0 |
| A | 0 | 226 | 3375 | 36.47 | 393 | 384 | 82.0 |
| B | 4 | 216 | 12166 | 149.96 | 395 | 385 | 78.6 |
| B | 12 | 111 | 9610 | 117.43 | 395 | 385 | 78.6 |
| B | 11 | 111 | 8134 | 98.64 | 395 | 385 | 78.6 |
| C | 3 | 233 | 314152 | 3428.43 | 381 | 384 | 91.5 |
| C | 14 | 238 | 57196 | 620.76 | 381 | 384 | 91.5 |
| C | 7 | 220 | 5791 | 59.08 | 381 | 384 | 91.5 |
| D | 10 | 66 | 15322 | 154.3 | 386 | 374 | 96.9 |
| D | 2 | 234 | 12252 | 122.61 | 386 | 374 | 96.9 |
| D | 11 | 176 | 4303 | 40.56 | 386 | 374 | 96.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
