| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C04_001T01_9000002846_19235cztM0_level2.evt | modeM0/AS1C04_001T01_9000002846_19235cztM0_level2_quad_clean.evt |
| Size (bytes) | 433,370,880 | 118,359,360 |
| Size | 413.3 MB | 112.9 MB |
| Events in quadrant A | 2,996,595 | 797,803 |
| Events in quadrant B | 3,054,469 | 816,550 |
| Events in quadrant C | 3,475,552 | 789,766 |
| Events in quadrant D | 3,202,870 | 774,279 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12745 | 1 |
| B | 0 | 12927 | 1 |
| C | 0 | 14300 | 1 |
| D | 0 | 13348 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5817 | 77 | 1.323706% |
| B | 5818 | 64 | 1.100034% |
| C | 5818 | 122 | 2.096941% |
| D | 5818 | 79 | 1.357855% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7117 | 5817 | 12 | 12 | 0.17% | 0.21% |  |
| B | 7118 | 5818 | 6 | 6 | 0.08% | 0.10% |  |
| C | 7118 | 5818 | 14 | 14 | 0.20% | 0.24% |  |
| D | 7118 | 5819 | 34 | 34 | 0.48% | 0.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 252 | 56209 | 373.83 | 752 | 739 | 148.4 |
| A | 13 | 170 | 37931 | 250.65 | 752 | 739 | 148.4 |
| A | 13 | 254 | 7430 | 45.09 | 752 | 739 | 148.4 |
| B | 0 | 190 | 32227 | 226.23 | 755 | 737 | 139.2 |
| B | 7 | 220 | 28615 | 200.28 | 755 | 737 | 139.2 |
| B | 3 | 64 | 17688 | 121.78 | 755 | 737 | 139.2 |
| C | 3 | 233 | 368453 | 2174.83 | 738 | 747 | 169.1 |
| C | 14 | 238 | 116976 | 687.45 | 738 | 747 | 169.1 |
| C | 0 | 207 | 110607 | 649.78 | 738 | 747 | 169.1 |
| D | 11 | 176 | 246985 | 1379.04 | 748 | 725 | 178.6 |
| D | 2 | 120 | 39326 | 216.16 | 748 | 725 | 178.6 |
| D | 1 | 52 | 36938 | 202.79 | 748 | 725 | 178.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
