| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C04_001T01_9000002846_19246cztM0_level2.evt | modeM0/AS1C04_001T01_9000002846_19246cztM0_level2_quad_clean.evt |
| Size (bytes) | 450,190,080 | 85,775,040 |
| Size | 429.3 MB | 81.8 MB |
| Events in quadrant A | 3,208,280 | 539,952 |
| Events in quadrant B | 3,256,355 | 546,129 |
| Events in quadrant C | 3,421,791 | 524,472 |
| Events in quadrant D | 3,290,255 | 518,033 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13889 | 12 |
| B | 0 | 13892 | 2 |
| C | 0 | 14062 | 10 |
| D | 0 | 14272 | 14 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6728 | 51 | 0.758026% |
| B | 6733 | 58 | 0.861429% |
| C | 6729 | 77 | 1.144301% |
| D | 6730 | 42 | 0.624071% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7743 | 6733 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7743 | 6734 | 3 | 3 | 0.04% | 0.04% |  |
| C | 7743 | 6734 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7743 | 6734 | 9 | 9 | 0.12% | 0.13% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 22290 | 127.87 | 825 | 806 | 168.0 |
| A | 13 | 254 | 8758 | 47.33 | 825 | 806 | 168.0 |
| A | 0 | 226 | 7152 | 37.77 | 825 | 806 | 168.0 |
| B | 12 | 111 | 19010 | 116.96 | 818 | 797 | 155.7 |
| B | 3 | 64 | 17087 | 104.61 | 818 | 797 | 155.7 |
| B | 11 | 111 | 16688 | 102.05 | 818 | 797 | 155.7 |
| C | 3 | 233 | 229457 | 1263.36 | 786 | 791 | 181.0 |
| C | 14 | 238 | 124659 | 684.36 | 786 | 791 | 181.0 |
| C | 13 | 61 | 5514 | 26.09 | 786 | 791 | 181.0 |
| D | 1 | 52 | 198827 | 1015.55 | 802 | 777 | 195.0 |
| D | 7 | 96 | 32077 | 160.5 | 802 | 777 | 195.0 |
| D | 2 | 234 | 28207 | 140.65 | 802 | 777 | 195.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
