| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_115T01_9000002848_19260cztM0_level2.evt | modeM0/AS1A05_115T01_9000002848_19260cztM0_level2_quad_clean.evt |
| Size (bytes) | 314,136,000 | 54,259,200 |
| Size | 299.6 MB | 51.7 MB |
| Events in quadrant A | 2,374,606 | 332,376 |
| Events in quadrant B | 2,206,016 | 338,344 |
| Events in quadrant C | 2,261,605 | 323,282 |
| Events in quadrant D | 2,352,125 | 320,109 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 96 | 0 |
| B | 0 | 96 | 0 |
| C | 0 | 96 | 0 |
| D | 0 | 96 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10012 | 1 |
| B | 0 | 9558 | 1 |
| C | 0 | 9617 | 1 |
| D | 0 | 10149 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4676 | 61 | 1.304534% |
| B | 4676 | 67 | 1.432849% |
| C | 4676 | 58 | 1.240376% |
| D | 4677 | 103 | 2.202266% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5451 | 4676 | 0 | 0 | 0.00% | 0.00% |  |
| B | 5451 | 4676 | 2 | 2 | 0.04% | 0.04% |  |
| C | 5451 | 4676 | 0 | 0 | 0.00% | 0.00% |  |
| D | 5452 | 4677 | 54 | 54 | 0.99% | 1.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 247 | 118619 | 1031.37 | 564 | 552 | 114.5 |
| A | 8 | 205 | 69523 | 602.49 | 564 | 552 | 114.5 |
| A | 3 | 1 | 8316 | 67.82 | 564 | 552 | 114.5 |
| B | 12 | 111 | 13696 | 119.7 | 559 | 545 | 109.9 |
| B | 3 | 64 | 12922 | 112.66 | 559 | 545 | 109.9 |
| B | 11 | 111 | 12158 | 105.7 | 559 | 545 | 109.9 |
| C | 14 | 238 | 83030 | 643.63 | 541 | 544 | 128.2 |
| C | 3 | 233 | 45573 | 351.36 | 541 | 544 | 128.2 |
| C | 9 | 54 | 22441 | 170.86 | 541 | 544 | 128.2 |
| D | 1 | 52 | 200953 | 1477.55 | 548 | 531 | 135.6 |
| D | 13 | 104 | 38883 | 282.74 | 548 | 531 | 135.6 |
| D | 7 | 238 | 34575 | 250.98 | 548 | 531 | 135.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
