| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_088T02_9000002850_19261cztM0_level2.evt | modeM0/AS1A05_088T02_9000002850_19261cztM0_level2_quad_clean.evt |
| Size (bytes) | 461,180,160 | 66,651,840 |
| Size | 439.8 MB | 63.6 MB |
| Events in quadrant A | 3,447,328 | 391,063 |
| Events in quadrant B | 3,389,020 | 397,717 |
| Events in quadrant C | 3,391,300 | 386,848 |
| Events in quadrant D | 3,291,357 | 382,625 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14439 | 3 |
| B | 0 | 14203 | 2 |
| C | 0 | 14062 | 2 |
| D | 0 | 14103 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6592 | 80 | 1.213592% |
| B | 6592 | 85 | 1.289442% |
| C | 6592 | 110 | 1.668689% |
| D | 6592 | 74 | 1.122573% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7657 | 6592 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7657 | 6592 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7657 | 6592 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7657 | 6592 | 8 | 8 | 0.10% | 0.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 205 | 143845 | 833.51 | 856 | 837 | 171.6 |
| A | 13 | 254 | 7663 | 39.78 | 856 | 837 | 171.6 |
| A | 0 | 226 | 7406 | 38.29 | 856 | 837 | 171.6 |
| B | 4 | 216 | 27029 | 163.89 | 846 | 827 | 159.9 |
| B | 12 | 111 | 19928 | 119.48 | 846 | 827 | 159.9 |
| B | 11 | 111 | 17643 | 105.18 | 846 | 827 | 159.9 |
| C | 14 | 238 | 129106 | 671.92 | 819 | 827 | 190.9 |
| C | 3 | 233 | 62204 | 321.49 | 819 | 827 | 190.9 |
| C | 9 | 54 | 7110 | 32.91 | 819 | 827 | 190.9 |
| D | 1 | 52 | 90310 | 436.81 | 836 | 811 | 204.9 |
| D | 7 | 238 | 27550 | 130.5 | 836 | 811 | 204.9 |
| D | 2 | 234 | 27330 | 129.43 | 836 | 811 | 204.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
