| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_107T01_9000002852_19279cztM0_level2.evt | modeM0/AS1A05_107T01_9000002852_19279cztM0_level2_quad_clean.evt |
| Size (bytes) | 480,885,120 | 87,687,360 |
| Size | 458.6 MB | 83.6 MB |
| Events in quadrant A | 3,421,616 | 557,771 |
| Events in quadrant B | 3,526,050 | 570,100 |
| Events in quadrant C | 3,562,382 | 554,070 |
| Events in quadrant D | 3,634,781 | 542,611 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14316 | 2 |
| B | 0 | 14623 | 2 |
| C | 0 | 14702 | 2 |
| D | 0 | 15144 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6171 | 89 | 1.442230% |
| B | 6171 | 107 | 1.733917% |
| C | 6171 | 139 | 2.252471% |
| D | 6171 | 137 | 2.220062% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7496 | 6171 | 4 | 4 | 0.05% | 0.06% |  |
| B | 7496 | 6171 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7496 | 6171 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7496 | 6171 | 42 | 42 | 0.56% | 0.68% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 17427 | 95.58 | 882 | 868 | 173.2 |
| A | 13 | 254 | 9289 | 48.61 | 882 | 868 | 173.2 |
| A | 0 | 226 | 7605 | 38.89 | 882 | 868 | 173.2 |
| B | 0 | 229 | 33100 | 196.38 | 879 | 859 | 164.2 |
| B | 12 | 111 | 18649 | 108.36 | 879 | 859 | 164.2 |
| B | 11 | 111 | 16460 | 95.03 | 879 | 859 | 164.2 |
| C | 14 | 238 | 134992 | 677.51 | 859 | 868 | 198.0 |
| C | 3 | 233 | 68499 | 341.63 | 859 | 868 | 198.0 |
| C | 9 | 15 | 8104 | 36.55 | 859 | 868 | 198.0 |
| D | 13 | 138 | 113293 | 534.34 | 868 | 846 | 210.4 |
| D | 1 | 52 | 72813 | 341.98 | 868 | 846 | 210.4 |
| D | 7 | 238 | 69956 | 328.41 | 868 | 846 | 210.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
