| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_107T01_9000002852_19284cztM0_level2.evt | modeM0/AS1A05_107T01_9000002852_19284cztM0_level2_quad_clean.evt |
| Size (bytes) | 562,190,400 | 112,717,440 |
| Size | 536.1 MB | 107.5 MB |
| Events in quadrant A | 3,904,487 | 716,390 |
| Events in quadrant B | 3,985,515 | 730,675 |
| Events in quadrant C | 4,050,718 | 714,393 |
| Events in quadrant D | 4,542,587 | 696,519 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17085 | 2 |
| B | 0 | 17209 | 2 |
| C | 0 | 17264 | 2 |
| D | 0 | 18937 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 164 | 0 |
| B | 0 | 164 | 0 |
| C | 0 | 164 | 0 |
| D | 0 | 164 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7984 | 185 | 2.317134% |
| B | 7985 | 253 | 3.168441% |
| C | 7985 | 325 | 4.070131% |
| D | 7985 | 119 | 1.490294% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8649 | 7986 | 3 | 3 | 0.03% | 0.04% |  |
| B | 8650 | 7987 | 2 | 2 | 0.02% | 0.03% |  |
| C | 8650 | 7985 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8650 | 7987 | 30 | 30 | 0.35% | 0.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 27690 | 130.49 | 1004 | 980 | 204.7 |
| A | 13 | 254 | 10134 | 44.72 | 1004 | 980 | 204.7 |
| A | 9 | 143 | 8813 | 38.27 | 1004 | 980 | 204.7 |
| B | 0 | 190 | 25904 | 128.41 | 1005 | 978 | 194.1 |
| B | 12 | 111 | 24470 | 121.02 | 1005 | 978 | 194.1 |
| B | 11 | 111 | 21129 | 103.81 | 1005 | 978 | 194.1 |
| C | 14 | 238 | 149758 | 645.3 | 977 | 984 | 230.6 |
| C | 3 | 233 | 82471 | 353.44 | 977 | 984 | 230.6 |
| C | 13 | 61 | 6991 | 26.05 | 977 | 984 | 230.6 |
| D | 7 | 223 | 642152 | 2655.52 | 986 | 960 | 241.5 |
| D | 1 | 52 | 93341 | 382.6 | 986 | 960 | 241.5 |
| D | 2 | 120 | 37001 | 149.26 | 986 | 960 | 241.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
