| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_204T01_9000002856_19329cztM0_level2.evt | modeM0/AS1A05_204T01_9000002856_19329cztM0_level2_quad_clean.evt |
| Size (bytes) | 663,203,520 | 96,868,800 |
| Size | 632.5 MB | 92.4 MB |
| Events in quadrant A | 3,558,564 | 629,632 |
| Events in quadrant B | 3,696,298 | 637,050 |
| Events in quadrant C | 3,720,141 | 612,119 |
| Events in quadrant D | 8,588,507 | 518,671 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15799 | 3 |
| B | 0 | 16125 | 3 |
| C | 0 | 16032 | 3 |
| D | 0 | 30787 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 160 | 0 |
| B | 0 | 160 | 0 |
| C | 0 | 160 | 0 |
| D | 0 | 160 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7691 | 46 | 0.598102% |
| B | 7691 | 101 | 1.313223% |
| C | 7690 | 113 | 1.469441% |
| D | 7691 | 1736 | 22.571837% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8221 | 7693 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8221 | 7694 | 15 | 15 | 0.18% | 0.19% |  |
| C | 8220 | 7692 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8221 | 7694 | 1629 | 1629 | 19.82% | 21.17% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 29 | 20072 | 103.05 | 913 | 891 | 186.1 |
| A | 4 | 2 | 17702 | 90.32 | 913 | 891 | 186.1 |
| A | 13 | 254 | 8300 | 39.81 | 913 | 891 | 186.1 |
| B | 3 | 64 | 67716 | 387.13 | 909 | 885 | 172.6 |
| B | 7 | 220 | 26564 | 148.75 | 909 | 885 | 172.6 |
| B | 12 | 111 | 21568 | 119.81 | 909 | 885 | 172.6 |
| C | 3 | 233 | 141556 | 675.81 | 882 | 886 | 208.1 |
| C | 14 | 238 | 134341 | 641.15 | 882 | 886 | 208.1 |
| C | 7 | 220 | 8117 | 34.74 | 882 | 886 | 208.1 |
| D | 7 | 238 | 4854304 | 24662.45 | 813 | 789 | 196.8 |
| D | 12 | 225 | 530440 | 2691.35 | 813 | 789 | 196.8 |
| D | 13 | 104 | 35195 | 174.83 | 813 | 789 | 196.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
