| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_226T09_9000002884_19416cztM0_level2.evt | modeM0/AS1A05_226T09_9000002884_19416cztM0_level2_quad_clean.evt |
| Size (bytes) | 751,109,760 | 112,852,800 |
| Size | 716.3 MB | 107.6 MB |
| Events in quadrant A | 3,894,920 | 779,111 |
| Events in quadrant B | 4,078,474 | 776,947 |
| Events in quadrant C | 4,030,432 | 734,087 |
| Events in quadrant D | 10,189,515 | 558,000 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16975 | 2 |
| B | 0 | 17381 | 2 |
| C | 0 | 17240 | 2 |
| D | 0 | 35862 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 168 | 0 |
| B | 0 | 168 | 0 |
| C | 0 | 168 | 0 |
| D | 0 | 168 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8182 | 43 | 0.525544% |
| B | 8182 | 81 | 0.989978% |
| C | 8182 | 92 | 1.124419% |
| D | 8183 | 2380 | 29.084688% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8887 | 8184 | 3 | 3 | 0.03% | 0.04% |  |
| B | 8887 | 8184 | 16 | 16 | 0.18% | 0.20% |  |
| C | 8887 | 8184 | 1 | 1 | 0.01% | 0.01% |  |
| D | 8887 | 8184 | 2077 | 2077 | 23.37% | 25.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 20153 | 94.38 | 1003 | 982 | 203.1 |
| A | 13 | 254 | 13232 | 60.31 | 1003 | 982 | 203.1 |
| A | 0 | 226 | 8605 | 37.53 | 1003 | 982 | 203.1 |
| B | 7 | 220 | 88075 | 452.51 | 994 | 968 | 192.5 |
| B | 12 | 111 | 23183 | 115.4 | 994 | 968 | 192.5 |
| B | 0 | 197 | 20617 | 102.07 | 994 | 968 | 192.5 |
| C | 3 | 233 | 151238 | 676.23 | 946 | 952 | 222.2 |
| C | 14 | 238 | 146633 | 655.51 | 946 | 952 | 222.2 |
| C | 9 | 221 | 19206 | 82.14 | 946 | 952 | 222.2 |
| D | 7 | 238 | 4447578 | 22318.74 | 820 | 794 | 199.2 |
| D | 1 | 52 | 2522139 | 12654.82 | 820 | 794 | 199.2 |
| D | 2 | 234 | 30674 | 149.97 | 820 | 794 | 199.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
