| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_009T02_9000002882_19413cztM0_level2.evt | modeM0/AS1A06_009T02_9000002882_19413cztM0_level2_quad_clean.evt |
| Size (bytes) | 238,106,880 | 39,165,120 |
| Size | 227.1 MB | 37.4 MB |
| Events in quadrant A | 1,592,477 | 246,215 |
| Events in quadrant B | 1,722,121 | 250,476 |
| Events in quadrant C | 1,621,791 | 239,074 |
| Events in quadrant D | 2,063,322 | 230,070 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6569 | 1 |
| B | 0 | 6987 | 1 |
| C | 0 | 6605 | 1 |
| D | 0 | 8023 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 64 | 0 |
| B | 0 | 64 | 0 |
| C | 0 | 64 | 0 |
| D | 0 | 64 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3084 | 68 | 2.204929% |
| B | 3084 | 84 | 2.723735% |
| C | 3084 | 85 | 2.756161% |
| D | 3084 | 131 | 4.247730% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3874 | 3084 | 1 | 1 | 0.03% | 0.03% |  |
| B | 3874 | 3084 | 0 | 0 | 0.00% | 0.00% |  |
| C | 3874 | 3084 | 1 | 1 | 0.03% | 0.03% |  |
| D | 3874 | 3085 | 93 | 93 | 2.40% | 3.01% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 19353 | 227.89 | 406 | 397 | 83.2 |
| A | 13 | 254 | 4740 | 52.21 | 406 | 397 | 83.2 |
| A | 11 | 29 | 3912 | 42.26 | 406 | 397 | 83.2 |
| B | 4 | 174 | 116877 | 1475.25 | 403 | 392 | 79.0 |
| B | 0 | 230 | 10507 | 128.1 | 403 | 392 | 79.0 |
| B | 12 | 111 | 9106 | 110.36 | 403 | 392 | 79.0 |
| C | 14 | 238 | 60357 | 659.64 | 386 | 390 | 90.9 |
| C | 3 | 233 | 36049 | 392.25 | 386 | 390 | 90.9 |
| C | 0 | 207 | 8645 | 90.81 | 386 | 390 | 90.9 |
| D | 7 | 238 | 557259 | 5759.49 | 392 | 381 | 96.7 |
| D | 2 | 234 | 12950 | 129.99 | 392 | 381 | 96.7 |
| D | 8 | 195 | 8711 | 86.15 | 392 | 381 | 96.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
