| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_028T01_9000002880_19410cztM0_level2.evt | modeM0/AS1T03_028T01_9000002880_19410cztM0_level2_quad_clean.evt |
| Size (bytes) | 618,641,280 | 77,446,080 |
| Size | 590.0 MB | 73.9 MB |
| Events in quadrant A | 3,459,790 | 518,960 |
| Events in quadrant B | 3,566,040 | 520,213 |
| Events in quadrant C | 3,460,689 | 485,588 |
| Events in quadrant D | 7,820,591 | 378,406 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14050 | 2 |
| B | 0 | 14419 | 1 |
| C | 0 | 13989 | 1 |
| D | 0 | 27601 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6342 | 98 | 1.545254% |
| B | 6343 | 100 | 1.576541% |
| C | 6343 | 123 | 1.939146% |
| D | 6271 | 1758 | 28.033806% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7652 | 6342 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7653 | 6343 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7653 | 6343 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7653 | 6271 | 1659 | 1659 | 21.68% | 26.46% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9015 | 45.7 | 896 | 879 | 178.0 |
| A | 0 | 226 | 7725 | 38.45 | 896 | 879 | 178.0 |
| A | 5 | 16 | 7422 | 36.75 | 896 | 879 | 178.0 |
| B | 0 | 190 | 28729 | 171.05 | 877 | 858 | 162.9 |
| B | 0 | 198 | 23154 | 136.83 | 877 | 858 | 162.9 |
| B | 7 | 220 | 21255 | 125.18 | 877 | 858 | 162.9 |
| C | 14 | 238 | 133899 | 695.6 | 833 | 841 | 191.3 |
| C | 3 | 233 | 48040 | 246.75 | 833 | 841 | 191.3 |
| C | 0 | 207 | 26202 | 132.58 | 833 | 841 | 191.3 |
| D | 10 | 66 | 3181500 | 18389.51 | 725 | 706 | 173.0 |
| D | 7 | 238 | 1791834 | 10355.26 | 725 | 706 | 173.0 |
| D | 5 | 222 | 57103 | 326.05 | 725 | 706 | 173.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
