| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_221T01_9000002888_19442cztM0_level2.evt | modeM0/AS1A05_221T01_9000002888_19442cztM0_level2_quad_clean.evt |
| Size (bytes) | 652,878,720 | 84,499,200 |
| Size | 622.6 MB | 80.6 MB |
| Events in quadrant A | 3,630,760 | 532,710 |
| Events in quadrant B | 3,690,327 | 538,436 |
| Events in quadrant C | 3,584,439 | 520,918 |
| Events in quadrant D | 8,387,649 | 473,458 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15171 | 2 |
| B | 0 | 15330 | 2 |
| C | 0 | 14978 | 2 |
| D | 0 | 29754 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7068 | 205 | 2.900396% |
| B | 7068 | 252 | 3.565365% |
| C | 7068 | 219 | 3.098472% |
| D | 7068 | 1533 | 21.689304% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8923 | 7068 | 9 | 9 | 0.10% | 0.13% |  |
| B | 8923 | 7068 | 2 | 2 | 0.02% | 0.03% |  |
| C | 8923 | 7068 | 5 | 5 | 0.06% | 0.07% |  |
| D | 8923 | 7068 | 1227 | 1227 | 13.75% | 17.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 70074 | 371.09 | 918 | 899 | 186.4 |
| A | 11 | 29 | 12329 | 61.32 | 918 | 899 | 186.4 |
| A | 3 | 1 | 11241 | 55.48 | 918 | 899 | 186.4 |
| B | 0 | 197 | 34098 | 185.61 | 912 | 890 | 178.9 |
| B | 0 | 198 | 21969 | 117.82 | 912 | 890 | 178.9 |
| B | 4 | 216 | 20845 | 111.53 | 912 | 890 | 178.9 |
| C | 14 | 238 | 134390 | 644.12 | 876 | 884 | 207.3 |
| C | 0 | 207 | 26493 | 123.55 | 876 | 884 | 207.3 |
| C | 3 | 233 | 8552 | 37.0 | 876 | 884 | 207.3 |
| D | 7 | 238 | 4397752 | 21440.35 | 837 | 812 | 205.1 |
| D | 1 | 52 | 654029 | 3185.22 | 837 | 812 | 205.1 |
| D | 10 | 230 | 69531 | 335.09 | 837 | 812 | 205.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
