| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_229T02_9000002890_19471cztM0_level2.evt | modeM0/AS1A05_229T02_9000002890_19471cztM0_level2_quad_clean.evt |
| Size (bytes) | 570,312,000 | 81,728,640 |
| Size | 543.9 MB | 77.9 MB |
| Events in quadrant A | 3,400,722 | 511,535 |
| Events in quadrant B | 3,614,505 | 517,010 |
| Events in quadrant C | 4,489,391 | 491,591 |
| Events in quadrant D | 5,301,319 | 475,493 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14378 | 3 |
| B | 0 | 15014 | 2 |
| C | 0 | 17997 | 2 |
| D | 0 | 20348 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6867 | 79 | 1.150430% |
| B | 6867 | 153 | 2.228047% |
| C | 6867 | 179 | 2.606670% |
| D | 6867 | 504 | 7.339450% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7642 | 6867 | 5 | 5 | 0.07% | 0.07% |  |
| B | 7642 | 6867 | 30 | 30 | 0.39% | 0.44% |  |
| C | 7642 | 6868 | 3 | 3 | 0.04% | 0.04% |  |
| D | 7642 | 6868 | 436 | 436 | 5.71% | 6.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 31521 | 173.99 | 867 | 847 | 176.3 |
| A | 11 | 29 | 13822 | 73.6 | 867 | 847 | 176.3 |
| A | 13 | 254 | 10346 | 53.88 | 867 | 847 | 176.3 |
| B | 3 | 64 | 126181 | 754.99 | 858 | 836 | 166.0 |
| B | 7 | 220 | 41500 | 244.93 | 858 | 836 | 166.0 |
| B | 6 | 36 | 40123 | 236.64 | 858 | 836 | 166.0 |
| C | 3 | 233 | 954956 | 4984.43 | 821 | 826 | 191.4 |
| C | 9 | 221 | 190388 | 990.28 | 821 | 826 | 191.4 |
| C | 14 | 238 | 127660 | 662.59 | 821 | 826 | 191.4 |
| D | 7 | 238 | 1771947 | 8881.78 | 817 | 793 | 199.4 |
| D | 12 | 225 | 159265 | 794.69 | 817 | 793 | 199.4 |
| D | 1 | 52 | 151566 | 756.08 | 817 | 793 | 199.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
