| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_229T02_9000002890_19482cztM0_level2.evt | modeM0/AS1A05_229T02_9000002890_19482cztM0_level2_quad_clean.evt |
| Size (bytes) | 589,484,160 | 79,456,320 |
| Size | 562.2 MB | 75.8 MB |
| Events in quadrant A | 3,426,489 | 507,030 |
| Events in quadrant B | 3,974,097 | 512,240 |
| Events in quadrant C | 3,531,154 | 485,398 |
| Events in quadrant D | 6,490,648 | 457,876 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13898 | 1 |
| B | 0 | 15773 | 1 |
| C | 0 | 14336 | 3 |
| D | 0 | 23712 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6351 | 68 | 1.070698% |
| B | 6351 | 178 | 2.802708% |
| C | 6351 | 97 | 1.527319% |
| D | 6351 | 868 | 13.667139% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7641 | 6351 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7641 | 6351 | 64 | 64 | 0.84% | 1.01% |  |
| C | 7641 | 6351 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7641 | 6351 | 706 | 706 | 9.24% | 11.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 29 | 19189 | 105.02 | 883 | 867 | 174.5 |
| A | 0 | 226 | 7880 | 40.2 | 883 | 867 | 174.5 |
| A | 3 | 137 | 6380 | 31.6 | 883 | 867 | 174.5 |
| B | 3 | 112 | 528363 | 3286.98 | 862 | 845 | 160.5 |
| B | 0 | 198 | 25510 | 153.69 | 862 | 845 | 160.5 |
| B | 12 | 111 | 18050 | 107.2 | 862 | 845 | 160.5 |
| C | 14 | 238 | 133528 | 695.61 | 834 | 844 | 190.7 |
| C | 9 | 221 | 76701 | 397.69 | 834 | 844 | 190.7 |
| C | 3 | 233 | 63593 | 328.97 | 834 | 844 | 190.7 |
| D | 7 | 238 | 1376972 | 7041.56 | 818 | 798 | 195.4 |
| D | 5 | 222 | 1322528 | 6762.98 | 818 | 798 | 195.4 |
| D | 1 | 52 | 432673 | 2209.8 | 818 | 798 | 195.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
