| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_142T01_9000002904_19543cztM0_level2.evt | modeM0/AS1A05_142T01_9000002904_19543cztM0_level2_quad_clean.evt |
| Size (bytes) | 487,523,520 | 71,167,680 |
| Size | 464.9 MB | 67.9 MB |
| Events in quadrant A | 3,418,234 | 425,937 |
| Events in quadrant B | 3,535,707 | 429,724 |
| Events in quadrant C | 3,712,376 | 411,414 |
| Events in quadrant D | 3,632,625 | 410,064 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14273 | 3 |
| B | 0 | 14548 | 3 |
| C | 0 | 15016 | 4 |
| D | 0 | 15148 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6853 | 117 | 1.707281% |
| B | 6853 | 131 | 1.911572% |
| C | 6852 | 150 | 2.189142% |
| D | 6852 | 113 | 1.649154% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7688 | 6854 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7688 | 6854 | 14 | 14 | 0.18% | 0.20% |  |
| C | 7687 | 6853 | 3 | 3 | 0.04% | 0.04% |  |
| D | 7687 | 6853 | 23 | 23 | 0.30% | 0.34% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 19475 | 104.95 | 880 | 860 | 177.4 |
| A | 13 | 254 | 9330 | 47.75 | 880 | 860 | 177.4 |
| A | 0 | 226 | 7730 | 38.73 | 880 | 860 | 177.4 |
| B | 0 | 198 | 44836 | 263.34 | 867 | 844 | 167.1 |
| B | 0 | 230 | 42027 | 246.52 | 867 | 844 | 167.1 |
| B | 3 | 64 | 40496 | 237.36 | 867 | 844 | 167.1 |
| C | 3 | 233 | 230433 | 1181.28 | 832 | 836 | 194.4 |
| C | 14 | 238 | 129740 | 663.22 | 832 | 836 | 194.4 |
| C | 7 | 247 | 104548 | 533.6 | 832 | 836 | 194.4 |
| D | 1 | 52 | 216634 | 1039.01 | 853 | 828 | 207.7 |
| D | 12 | 218 | 127993 | 612.25 | 853 | 828 | 207.7 |
| D | 12 | 225 | 45164 | 213.46 | 853 | 828 | 207.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
