| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_142T01_9000002904_19549cztM0_level2.evt | modeM0/AS1A05_142T01_9000002904_19549cztM0_level2_quad_clean.evt |
| Size (bytes) | 434,306,880 | 76,556,160 |
| Size | 414.2 MB | 73.0 MB |
| Events in quadrant A | 2,999,105 | 473,600 |
| Events in quadrant B | 3,105,775 | 475,339 |
| Events in quadrant C | 3,176,960 | 462,668 |
| Events in quadrant D | 3,433,767 | 457,792 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13130 | 2 |
| B | 0 | 13351 | 2 |
| C | 0 | 13522 | 2 |
| D | 0 | 14594 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6434 | 26 | 0.404103% |
| B | 6434 | 43 | 0.668325% |
| C | 6434 | 86 | 1.336649% |
| D | 6434 | 81 | 1.258937% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7019 | 6435 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7019 | 6435 | 5 | 5 | 0.07% | 0.08% |  |
| C | 7019 | 6435 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7019 | 6435 | 48 | 48 | 0.68% | 0.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10134 | 58.86 | 777 | 759 | 159.3 |
| A | 0 | 226 | 6699 | 37.3 | 777 | 759 | 159.3 |
| A | 3 | 137 | 6517 | 36.15 | 777 | 759 | 159.3 |
| B | 3 | 64 | 34491 | 226.27 | 770 | 749 | 149.1 |
| B | 0 | 230 | 18627 | 119.89 | 770 | 749 | 149.1 |
| B | 12 | 111 | 18251 | 117.36 | 770 | 749 | 149.1 |
| C | 14 | 238 | 116070 | 656.59 | 742 | 745 | 175.6 |
| C | 3 | 233 | 81520 | 459.88 | 742 | 745 | 175.6 |
| C | 7 | 247 | 77322 | 435.98 | 742 | 745 | 175.6 |
| D | 2 | 16 | 239404 | 1292.88 | 754 | 731 | 184.6 |
| D | 10 | 230 | 186646 | 1007.09 | 754 | 731 | 184.6 |
| D | 12 | 233 | 80158 | 430.25 | 754 | 731 | 184.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
