| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_115T01_9000002914_19597cztM0_level2.evt | modeM0/AS1T03_115T01_9000002914_19597cztM0_level2_quad_clean.evt |
| Size (bytes) | 368,565,120 | 90,973,440 |
| Size | 351.5 MB | 86.8 MB |
| Events in quadrant A | 2,624,652 | 604,958 |
| Events in quadrant B | 2,655,417 | 624,588 |
| Events in quadrant C | 2,695,661 | 589,294 |
| Events in quadrant D | 2,825,527 | 565,240 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 8 |
| B | 0 | 14 | 9 |
| C | 0 | 13 | 8 |
| D | 0 | 14 | 10 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 18 |
| B | 0 | 122 | 16 |
| C | 0 | 121 | 15 |
| D | 0 | 122 | 14 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12673 | 1571 |
| B | 0 | 12771 | 1556 |
| C | 0 | 13051 | 1571 |
| D | 0 | 14389 | 2462 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5317 | 9 | 0.169268% |
| B | 5303 | 10 | 0.188573% |
| C | 5300 | 29 | 0.547170% |
| D | 5277 | 46 | 0.871707% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7278 | 5386 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7255 | 5376 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7265 | 5371 | 2 | 2 | 0.03% | 0.04% |  |
| D | 7255 | 5339 | 40 | 40 | 0.55% | 0.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 29 | 45262 | 333.44 | 664 | 654 | 133.8 |
| A | 11 | 47 | 13453 | 95.67 | 664 | 654 | 133.8 |
| A | 13 | 254 | 7440 | 50.72 | 664 | 654 | 133.8 |
| B | 12 | 111 | 14108 | 108.52 | 667 | 652 | 124.0 |
| B | 4 | 216 | 14018 | 107.8 | 667 | 652 | 124.0 |
| B | 11 | 111 | 12152 | 92.75 | 667 | 652 | 124.0 |
| C | 5 | 112 | 101648 | 694.55 | 633 | 640 | 145.4 |
| C | 14 | 238 | 101563 | 693.96 | 633 | 640 | 145.4 |
| C | 9 | 221 | 12484 | 81.44 | 633 | 640 | 145.4 |
| D | 1 | 52 | 182128 | 1191.95 | 629 | 612 | 152.3 |
| D | 7 | 38 | 148437 | 970.72 | 629 | 612 | 152.3 |
| D | 7 | 238 | 53605 | 347.99 | 629 | 612 | 152.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
