| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_115T01_9000002914_19600cztM0_level2.evt | modeM0/AS1T03_115T01_9000002914_19600cztM0_level2_quad_clean.evt |
| Size (bytes) | 446,909,760 | 90,823,680 |
| Size | 426.2 MB | 86.6 MB |
| Events in quadrant A | 3,134,372 | 587,534 |
| Events in quadrant B | 3,182,125 | 594,191 |
| Events in quadrant C | 3,141,648 | 567,920 |
| Events in quadrant D | 3,644,326 | 557,099 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13188 | 1 |
| B | 0 | 13395 | 1 |
| C | 0 | 13365 | 1 |
| D | 0 | 15137 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6361 | 65 | 1.021852% |
| B | 6362 | 89 | 1.398931% |
| C | 6362 | 75 | 1.178875% |
| D | 6362 | 189 | 2.970764% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7426 | 6362 | 6 | 6 | 0.08% | 0.09% |  |
| B | 7427 | 6364 | 9 | 9 | 0.12% | 0.14% |  |
| C | 7427 | 6364 | 6 | 6 | 0.08% | 0.09% |  |
| D | 7427 | 6364 | 127 | 127 | 1.71% | 2.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 53353 | 330.61 | 785 | 769 | 159.1 |
| A | 11 | 29 | 50429 | 312.22 | 785 | 769 | 159.1 |
| A | 13 | 254 | 8319 | 47.47 | 785 | 769 | 159.1 |
| B | 4 | 216 | 37741 | 248.87 | 780 | 761 | 148.6 |
| B | 0 | 197 | 26335 | 172.11 | 780 | 761 | 148.6 |
| B | 15 | 32 | 19385 | 125.33 | 780 | 761 | 148.6 |
| C | 3 | 233 | 119248 | 687.42 | 742 | 745 | 172.4 |
| C | 14 | 238 | 116516 | 671.57 | 742 | 745 | 172.4 |
| C | 5 | 112 | 9493 | 50.75 | 742 | 745 | 172.4 |
| D | 1 | 52 | 454037 | 2514.62 | 749 | 727 | 180.3 |
| D | 7 | 38 | 251999 | 1393.87 | 749 | 727 | 180.3 |
| D | 13 | 172 | 24312 | 130.83 | 749 | 727 | 180.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
