| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_115T01_9000002914_19603cztM0_level2.evt | modeM0/AS1T03_115T01_9000002914_19603cztM0_level2_quad_clean.evt |
| Size (bytes) | 512,599,680 | 95,002,560 |
| Size | 488.9 MB | 90.6 MB |
| Events in quadrant A | 3,741,093 | 615,532 |
| Events in quadrant B | 3,871,437 | 582,525 |
| Events in quadrant C | 3,705,493 | 561,941 |
| Events in quadrant D | 3,690,384 | 588,747 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16037 | 1 |
| B | 0 | 16257 | 1 |
| C | 0 | 15826 | 1 |
| D | 0 | 16095 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7588 | 217 | 2.859779% |
| B | 7588 | 265 | 3.492356% |
| C | 7588 | 258 | 3.400105% |
| D | 7588 | 179 | 2.358988% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7663 | 7589 | 7 | 7 | 0.09% | 0.09% |  |
| B | 7663 | 7588 | 29 | 29 | 0.38% | 0.38% |  |
| C | 7663 | 7588 | 4 | 4 | 0.05% | 0.05% |  |
| D | 7663 | 7589 | 15 | 15 | 0.20% | 0.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 25735 | 127.51 | 956 | 937 | 194.5 |
| A | 11 | 29 | 22505 | 110.9 | 956 | 937 | 194.5 |
| A | 4 | 2 | 12903 | 61.53 | 956 | 937 | 194.5 |
| B | 4 | 216 | 76056 | 416.8 | 932 | 911 | 180.3 |
| B | 7 | 220 | 61654 | 336.92 | 932 | 911 | 180.3 |
| B | 3 | 64 | 33511 | 180.82 | 932 | 911 | 180.3 |
| C | 14 | 238 | 136769 | 643.07 | 893 | 899 | 211.3 |
| C | 3 | 233 | 43087 | 199.67 | 893 | 899 | 211.3 |
| C | 5 | 112 | 39245 | 181.49 | 893 | 899 | 211.3 |
| D | 1 | 52 | 129382 | 566.89 | 926 | 900 | 226.6 |
| D | 2 | 234 | 32885 | 141.12 | 926 | 900 | 226.6 |
| D | 13 | 172 | 23933 | 101.63 | 926 | 900 | 226.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
