| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C04_001T01_9000002948_19738cztM0_level2.evt | modeM0/AS1C04_001T01_9000002948_19738cztM0_level2_quad_clean.evt |
| Size (bytes) | 548,521,920 | 123,292,800 |
| Size | 523.1 MB | 117.6 MB |
| Events in quadrant A | 3,109,327 | 844,179 |
| Events in quadrant B | 3,274,822 | 855,818 |
| Events in quadrant C | 3,287,542 | 828,809 |
| Events in quadrant D | 6,490,704 | 742,984 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13723 | 2 |
| B | 0 | 14171 | 2 |
| C | 0 | 14274 | 2 |
| D | 0 | 23989 | 7 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6629 | 25 | 0.377131% |
| B | 6629 | 35 | 0.527983% |
| C | 6629 | 61 | 0.920199% |
| D | 6628 | 1116 | 16.837658% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7634 | 6630 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7634 | 6630 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7634 | 6630 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7633 | 6629 | 881 | 881 | 11.54% | 13.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 50632 | 312.1 | 788 | 769 | 159.8 |
| A | 8 | 205 | 14903 | 88.47 | 788 | 769 | 159.8 |
| A | 13 | 254 | 7090 | 39.56 | 788 | 769 | 159.8 |
| B | 4 | 216 | 45931 | 297.91 | 790 | 769 | 151.6 |
| B | 0 | 197 | 42614 | 276.03 | 790 | 769 | 151.6 |
| B | 4 | 171 | 34418 | 221.97 | 790 | 769 | 151.6 |
| C | 3 | 233 | 165924 | 920.53 | 767 | 772 | 179.4 |
| C | 14 | 238 | 119532 | 661.95 | 767 | 772 | 179.4 |
| C | 7 | 247 | 6871 | 33.99 | 767 | 772 | 179.4 |
| D | 1 | 52 | 2675560 | 15185.47 | 724 | 700 | 176.1 |
| D | 9 | 1 | 724440 | 4108.75 | 724 | 700 | 176.1 |
| D | 13 | 172 | 154804 | 874.86 | 724 | 700 | 176.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
