| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C04_001T01_9000002948_19753cztM0_level2.evt | modeM0/AS1C04_001T01_9000002948_19753cztM0_level2_quad_clean.evt |
| Size (bytes) | 525,421,440 | 120,142,080 |
| Size | 501.1 MB | 114.6 MB |
| Events in quadrant A | 3,005,404 | 818,057 |
| Events in quadrant B | 3,322,365 | 826,063 |
| Events in quadrant C | 3,507,174 | 804,318 |
| Events in quadrant D | 5,637,885 | 738,078 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13397 | 2 |
| B | 0 | 14355 | 2 |
| C | 0 | 14695 | 2 |
| D | 0 | 21451 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6481 | 18 | 0.277735% |
| B | 6481 | 80 | 1.234377% |
| C | 6481 | 106 | 1.635550% |
| D | 6481 | 772 | 11.911742% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7566 | 6482 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7566 | 6482 | 39 | 39 | 0.52% | 0.60% |  |
| C | 7566 | 6481 | 6 | 6 | 0.08% | 0.09% |  |
| D | 7566 | 6482 | 562 | 562 | 7.43% | 8.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 6817 | 38.61 | 779 | 760 | 156.9 |
| A | 13 | 254 | 6253 | 35.02 | 779 | 760 | 156.9 |
| A | 3 | 137 | 5957 | 33.13 | 779 | 760 | 156.9 |
| B | 7 | 220 | 232325 | 1591.17 | 776 | 757 | 145.5 |
| B | 0 | 197 | 25260 | 168.37 | 776 | 757 | 145.5 |
| B | 12 | 111 | 17015 | 111.71 | 776 | 757 | 145.5 |
| C | 3 | 233 | 364894 | 2064.5 | 757 | 762 | 176.4 |
| C | 14 | 238 | 118612 | 668.17 | 757 | 762 | 176.4 |
| C | 3 | 247 | 71390 | 400.44 | 757 | 762 | 176.4 |
| D | 1 | 52 | 1772910 | 10092.14 | 727 | 706 | 175.6 |
| D | 7 | 238 | 504774 | 2870.51 | 727 | 706 | 175.6 |
| D | 12 | 110 | 191936 | 1088.99 | 727 | 706 | 175.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
