| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_022T08_9000002950_19761cztM0_level2.evt | modeM0/AS1A05_022T08_9000002950_19761cztM0_level2_quad_clean.evt |
| Size (bytes) | 726,030,720 | 73,186,560 |
| Size | 692.4 MB | 69.8 MB |
| Events in quadrant A | 3,458,217 | 453,404 |
| Events in quadrant B | 3,778,384 | 457,388 |
| Events in quadrant C | 6,067,224 | 418,709 |
| Events in quadrant D | 8,199,055 | 386,347 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14895 | 3 |
| B | 0 | 15737 | 2 |
| C | 0 | 22963 | 2 |
| D | 0 | 29222 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7182 | 67 | 0.932888% |
| B | 7182 | 151 | 2.102478% |
| C | 7182 | 432 | 6.015038% |
| D | 7182 | 1707 | 23.767753% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7752 | 7183 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7752 | 7182 | 50 | 50 | 0.64% | 0.70% |  |
| C | 7752 | 7183 | 175 | 175 | 2.26% | 2.44% |  |
| D | 7752 | 7182 | 1382 | 1382 | 17.83% | 19.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 48032 | 263.98 | 880 | 860 | 178.7 |
| A | 0 | 23 | 12800 | 66.82 | 880 | 860 | 178.7 |
| A | 0 | 226 | 8342 | 41.87 | 880 | 860 | 178.7 |
| B | 4 | 216 | 181309 | 1056.87 | 883 | 861 | 170.7 |
| B | 7 | 220 | 94661 | 549.38 | 883 | 861 | 170.7 |
| B | 12 | 111 | 20879 | 117.24 | 883 | 861 | 170.7 |
| C | 3 | 233 | 2694302 | 13722.44 | 831 | 837 | 196.3 |
| C | 14 | 238 | 129016 | 653.04 | 831 | 837 | 196.3 |
| C | 13 | 61 | 6003 | 26.32 | 831 | 837 | 196.3 |
| D | 7 | 238 | 3518614 | 19741.42 | 728 | 708 | 178.2 |
| D | 1 | 52 | 1498760 | 8406.61 | 728 | 708 | 178.2 |
| D | 12 | 218 | 164998 | 921.95 | 728 | 708 | 178.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
