| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_117T01_9000002958_19795cztM0_level2.evt | modeM0/AS1A05_117T01_9000002958_19795cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,156,581,440 | 295,456,320 |
| Size | 2.0 GB | 281.8 MB |
| Events in quadrant A | 24,061,861 | 1,720,083 |
| Events in quadrant B | 11,990,222 | 1,909,716 |
| Events in quadrant C | 13,768,796 | 1,808,027 |
| Events in quadrant D | 13,827,018 | 1,809,715 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 88245 | 5 |
| B | 0 | 51556 | 5 |
| C | 0 | 56644 | 5 |
| D | 0 | 57442 | 5 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 502 | 0 |
| B | 0 | 502 | 0 |
| C | 0 | 502 | 0 |
| D | 0 | 502 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 24711 | 3423 | 13.852131% |
| B | 24712 | 467 | 1.889770% |
| C | 24712 | 951 | 3.848333% |
| D | 24712 | 636 | 2.573648% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 26951 | 24712 | 2510 | 2510 | 9.31% | 10.16% |  |
| B | 26952 | 24713 | 30 | 30 | 0.11% | 0.12% |  |
| C | 26952 | 24714 | 323 | 323 | 1.20% | 1.31% |  |
| D | 26952 | 24714 | 294 | 294 | 1.09% | 1.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 12573409 | 22221.57 | 2813 | 2748 | 565.7 |
| A | 10 | 253 | 571669 | 1005.7 | 2813 | 2748 | 565.7 |
| A | 9 | 143 | 85613 | 146.48 | 2813 | 2748 | 565.7 |
| B | 7 | 220 | 325493 | 573.33 | 2945 | 2864 | 562.7 |
| B | 12 | 111 | 69448 | 118.32 | 2945 | 2864 | 562.7 |
| B | 11 | 111 | 62193 | 105.43 | 2945 | 2864 | 562.7 |
| C | 3 | 233 | 2313014 | 3520.82 | 2820 | 2834 | 656.1 |
| C | 14 | 238 | 434354 | 657.66 | 2820 | 2834 | 656.1 |
| C | 7 | 247 | 22537 | 30.03 | 2820 | 2834 | 656.1 |
| D | 7 | 238 | 1646817 | 2361.88 | 2895 | 2815 | 696.1 |
| D | 2 | 184 | 566492 | 809.81 | 2895 | 2815 | 696.1 |
| D | 12 | 218 | 179662 | 254.07 | 2895 | 2815 | 696.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
