| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_117T01_9000002958_19798cztM0_level2.evt | modeM0/AS1A05_117T01_9000002958_19798cztM0_level2_quad_clean.evt |
| Size (bytes) | 629,081,280 | 69,010,560 |
| Size | 599.9 MB | 65.8 MB |
| Events in quadrant A | 6,710,418 | 392,516 |
| Events in quadrant B | 3,460,634 | 431,392 |
| Events in quadrant C | 3,494,925 | 409,001 |
| Events in quadrant D | 4,951,163 | 408,446 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24350 | 4 |
| B | 0 | 14465 | 2 |
| C | 0 | 14422 | 2 |
| D | 0 | 19205 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6419 | 1061 | 16.529054% |
| B | 6419 | 129 | 2.009659% |
| C | 6419 | 91 | 1.417666% |
| D | 6419 | 655 | 10.204082% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7534 | 6419 | 854 | 854 | 11.34% | 13.30% |  |
| B | 7534 | 6419 | 35 | 35 | 0.46% | 0.55% |  |
| C | 7534 | 6419 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7534 | 6419 | 502 | 502 | 6.66% | 7.82% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 3738360 | 24290.56 | 770 | 755 | 153.9 |
| A | 0 | 226 | 6673 | 38.46 | 770 | 755 | 153.9 |
| A | 3 | 137 | 6118 | 34.85 | 770 | 755 | 153.9 |
| B | 7 | 220 | 164263 | 1063.56 | 814 | 794 | 153.7 |
| B | 10 | 247 | 31848 | 202.04 | 814 | 794 | 153.7 |
| B | 4 | 216 | 28323 | 179.11 | 814 | 794 | 153.7 |
| C | 3 | 233 | 331457 | 1818.87 | 780 | 787 | 181.8 |
| C | 14 | 238 | 121718 | 665.19 | 780 | 787 | 181.8 |
| C | 13 | 61 | 5495 | 25.89 | 780 | 787 | 181.8 |
| D | 7 | 238 | 1488727 | 7962.02 | 765 | 741 | 186.9 |
| D | 12 | 218 | 421950 | 2253.83 | 765 | 741 | 186.9 |
| D | 2 | 69 | 100711 | 534.92 | 765 | 741 | 186.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
