| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_155T04_9000002956_19778cztM0_level2.evt | modeM0/AS1A05_155T04_9000002956_19778cztM0_level2_quad_clean.evt |
| Size (bytes) | 594,169,920 | 77,826,240 |
| Size | 566.6 MB | 74.2 MB |
| Events in quadrant A | 3,603,422 | 471,429 |
| Events in quadrant B | 3,677,111 | 479,428 |
| Events in quadrant C | 4,926,074 | 457,136 |
| Events in quadrant D | 5,269,211 | 416,741 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 0 |
| B | 0 | 158 | 0 |
| C | 0 | 158 | 0 |
| D | 0 | 158 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15729 | 2 |
| B | 0 | 15854 | 2 |
| C | 0 | 19504 | 3 |
| D | 0 | 20876 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7644 | 184 | 2.407117% |
| B | 7644 | 201 | 2.629513% |
| C | 7643 | 610 | 7.981159% |
| D | 7643 | 777 | 10.166165% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8049 | 7646 | 1 | 1 | 0.01% | 0.01% |  |
| B | 8049 | 7645 | 4 | 4 | 0.05% | 0.05% |  |
| C | 8048 | 7645 | 270 | 270 | 3.35% | 3.53% |  |
| D | 8048 | 7644 | 507 | 507 | 6.30% | 6.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 23216 | 117.95 | 926 | 907 | 189.1 |
| A | 11 | 29 | 11407 | 55.51 | 926 | 907 | 189.1 |
| A | 13 | 254 | 8526 | 40.28 | 926 | 907 | 189.1 |
| B | 3 | 64 | 50092 | 274.05 | 922 | 896 | 179.5 |
| B | 12 | 111 | 22672 | 121.3 | 922 | 896 | 179.5 |
| B | 11 | 111 | 20347 | 108.35 | 922 | 896 | 179.5 |
| C | 3 | 233 | 1365653 | 6703.53 | 864 | 869 | 203.6 |
| C | 14 | 238 | 133558 | 651.74 | 864 | 869 | 203.6 |
| C | 7 | 247 | 51280 | 247.61 | 864 | 869 | 203.6 |
| D | 1 | 52 | 1852053 | 8816.71 | 855 | 827 | 210.0 |
| D | 7 | 238 | 127375 | 602.7 | 855 | 827 | 210.0 |
| D | 12 | 218 | 59119 | 277.62 | 855 | 827 | 210.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
