| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_118T01_9000002962_19820cztM0_level2.evt | modeM0/AS1T03_118T01_9000002962_19820cztM0_level2_quad_clean.evt |
| Size (bytes) | 536,711,040 | 97,833,600 |
| Size | 511.8 MB | 93.3 MB |
| Events in quadrant A | 3,576,375 | 636,125 |
| Events in quadrant B | 3,505,190 | 647,059 |
| Events in quadrant C | 3,448,358 | 619,269 |
| Events in quadrant D | 5,229,514 | 552,700 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15384 | 1 |
| B | 0 | 15158 | 2 |
| C | 0 | 14970 | 1 |
| D | 0 | 20534 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7289 | 214 | 2.935931% |
| B | 7288 | 212 | 2.908891% |
| C | 7288 | 215 | 2.950055% |
| D | 7289 | 830 | 11.387022% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7394 | 7290 | 11 | 11 | 0.15% | 0.15% |  |
| B | 7393 | 7289 | 3 | 3 | 0.04% | 0.04% |  |
| C | 7393 | 7289 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7394 | 7289 | 580 | 580 | 7.84% | 7.96% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 115496 | 635.31 | 884 | 863 | 180.4 |
| A | 9 | 143 | 27395 | 147.04 | 884 | 863 | 180.4 |
| A | 5 | 16 | 12048 | 61.99 | 884 | 863 | 180.4 |
| B | 7 | 220 | 34634 | 198.53 | 879 | 855 | 170.1 |
| B | 12 | 111 | 20539 | 115.69 | 879 | 855 | 170.1 |
| B | 11 | 111 | 18247 | 102.22 | 879 | 855 | 170.1 |
| C | 14 | 238 | 130176 | 643.83 | 850 | 853 | 200.9 |
| C | 13 | 61 | 5841 | 24.83 | 850 | 853 | 200.9 |
| C | 3 | 233 | 2927 | 10.33 | 850 | 853 | 200.9 |
| D | 1 | 52 | 1815388 | 9055.5 | 819 | 795 | 200.4 |
| D | 12 | 218 | 260117 | 1294.11 | 819 | 795 | 200.4 |
| D | 2 | 234 | 35145 | 171.42 | 819 | 795 | 200.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
