| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_118T01_9000002962_19830cztM0_level2.evt | modeM0/AS1T03_118T01_9000002962_19830cztM0_level2_quad_clean.evt |
| Size (bytes) | 476,144,640 | 108,008,640 |
| Size | 454.1 MB | 103.0 MB |
| Events in quadrant A | 3,951,350 | 714,334 |
| Events in quadrant B | 3,360,344 | 738,481 |
| Events in quadrant C | 3,232,468 | 712,133 |
| Events in quadrant D | 3,464,306 | 682,724 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15621 | 2 |
| B | 0 | 13792 | 2 |
| C | 0 | 13330 | 2 |
| D | 0 | 14275 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6065 | 229 | 3.775763% |
| B | 6064 | 79 | 1.302770% |
| C | 6064 | 81 | 1.335752% |
| D | 6064 | 85 | 1.401715% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7420 | 6066 | 100 | 100 | 1.35% | 1.65% |  |
| B | 7419 | 6065 | 8 | 8 | 0.11% | 0.13% |  |
| C | 7419 | 6065 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7419 | 6065 | 46 | 46 | 0.62% | 0.76% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 790793 | 4925.12 | 806 | 791 | 160.4 |
| A | 14 | 254 | 62826 | 386.75 | 806 | 791 | 160.4 |
| A | 0 | 226 | 6808 | 37.51 | 806 | 791 | 160.4 |
| B | 10 | 245 | 75724 | 486.84 | 816 | 797 | 153.9 |
| B | 0 | 197 | 35228 | 223.72 | 816 | 797 | 153.9 |
| B | 7 | 220 | 20076 | 125.27 | 816 | 797 | 153.9 |
| C | 14 | 238 | 124340 | 663.51 | 797 | 804 | 186.2 |
| C | 13 | 61 | 5606 | 25.79 | 797 | 804 | 186.2 |
| C | 3 | 233 | 3272 | 13.26 | 797 | 804 | 186.2 |
| D | 1 | 52 | 285200 | 1492.0 | 796 | 775 | 190.6 |
| D | 7 | 96 | 89433 | 465.07 | 796 | 775 | 190.6 |
| D | 10 | 199 | 41045 | 211.24 | 796 | 775 | 190.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
