| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_118T01_9000002962_19846cztM0_level2.evt | modeM0/AS1T03_118T01_9000002962_19846cztM0_level2_quad_clean.evt |
| Size (bytes) | 582,497,280 | 98,631,360 |
| Size | 555.5 MB | 94.1 MB |
| Events in quadrant A | 7,316,049 | 587,658 |
| Events in quadrant B | 3,201,117 | 678,158 |
| Events in quadrant C | 3,248,024 | 651,068 |
| Events in quadrant D | 3,449,509 | 630,758 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26053 | 2 |
| B | 0 | 13416 | 2 |
| C | 0 | 13421 | 2 |
| D | 0 | 14483 | 4 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6290 | 1414 | 22.480127% |
| B | 6290 | 72 | 1.144674% |
| C | 6290 | 70 | 1.112878% |
| D | 6289 | 109 | 1.733185% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7485 | 6291 | 986 | 986 | 13.17% | 15.67% |  |
| B | 7485 | 6291 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7485 | 6290 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7484 | 6290 | 54 | 54 | 0.72% | 0.86% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 4355734 | 29683.99 | 725 | 710 | 146.7 |
| A | 14 | 254 | 96735 | 654.51 | 725 | 710 | 146.7 |
| A | 5 | 16 | 77342 | 522.33 | 725 | 710 | 146.7 |
| B | 12 | 111 | 18257 | 114.56 | 808 | 788 | 152.5 |
| B | 11 | 111 | 16084 | 100.31 | 808 | 788 | 152.5 |
| B | 14 | 111 | 14393 | 89.22 | 808 | 788 | 152.5 |
| C | 14 | 238 | 121966 | 653.6 | 788 | 797 | 185.4 |
| C | 9 | 221 | 48150 | 255.43 | 788 | 797 | 185.4 |
| C | 13 | 61 | 5288 | 24.22 | 788 | 797 | 185.4 |
| D | 1 | 52 | 412455 | 2164.02 | 786 | 764 | 190.2 |
| D | 12 | 218 | 37822 | 194.79 | 786 | 764 | 190.2 |
| D | 7 | 96 | 34707 | 178.42 | 786 | 764 | 190.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
