| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_118T01_9000002962_19879cztM0_level2.evt | modeM0/AS1T03_118T01_9000002962_19879cztM0_level2_quad_clean.evt |
| Size (bytes) | 573,503,040 | 107,251,200 |
| Size | 546.9 MB | 102.3 MB |
| Events in quadrant A | 4,693,232 | 687,575 |
| Events in quadrant B | 3,742,138 | 700,810 |
| Events in quadrant C | 3,808,335 | 667,108 |
| Events in quadrant D | 4,598,714 | 653,108 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 0 |
| B | 0 | 158 | 0 |
| C | 0 | 158 | 0 |
| D | 0 | 158 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18956 | 2 |
| B | 0 | 16091 | 2 |
| C | 0 | 16293 | 2 |
| D | 0 | 19013 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7757 | 315 | 4.060848% |
| B | 7757 | 225 | 2.900606% |
| C | 7758 | 233 | 3.003351% |
| D | 7758 | 310 | 3.995875% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8320 | 7775 | 63 | 63 | 0.76% | 0.81% |  |
| B | 8320 | 7775 | 0 | 0 | 0.00% | 0.00% |  |
| C | 8321 | 7778 | 3 | 3 | 0.04% | 0.04% |  |
| D | 8321 | 7777 | 106 | 106 | 1.27% | 1.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 1075603 | 5581.38 | 941 | 921 | 192.5 |
| A | 3 | 137 | 7958 | 36.55 | 941 | 921 | 192.5 |
| A | 0 | 226 | 7956 | 36.54 | 941 | 921 | 192.5 |
| B | 12 | 111 | 22584 | 118.89 | 938 | 912 | 182.3 |
| B | 11 | 111 | 20182 | 105.72 | 938 | 912 | 182.3 |
| B | 14 | 111 | 17996 | 93.72 | 938 | 912 | 182.3 |
| C | 14 | 238 | 138756 | 646.97 | 904 | 910 | 213.1 |
| C | 9 | 221 | 123941 | 577.43 | 904 | 910 | 213.1 |
| C | 7 | 220 | 14565 | 64.09 | 904 | 910 | 213.1 |
| D | 2 | 184 | 1059312 | 4740.84 | 917 | 891 | 223.3 |
| D | 10 | 199 | 35108 | 153.26 | 917 | 891 | 223.3 |
| D | 2 | 234 | 30068 | 130.69 | 917 | 891 | 223.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
